EXL-132 < ECU DIAGNOSIS > [XENON TYPE] BCM (BODY CONTROL MODULE) 107 (LG) Ground Combination switch Input Combination All switch OFF 1.4 V Turn signal switch LH 1.3 V Turn signal switch RH 1.3 V Front wiper switch LO 1.3 V Front washer switch ON 1.3 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JPMIA0041GB JPMIA0037GB JPMIA0036GB JPMIA0038GB JPMIA0039GB |
