Infiniti G37 Coupe. Manual - part 190
AV
BOSE AMP.
AV-513
< ECU DIAGNOSIS >
[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
M
B
A
O
P
29
(L)
30
(O)
Sound signal center speak-
er
Output
Ignition
switch
ON
Voice output
31
(LG)
32
(Y)
Sound signal rear speaker
RH
Output
Ignition
switch
ON
Voice output
33
(R)
34
(G)
Sound signal front RH
Input
Ignition
switch
ON
Voice output
35
(P)
36
(L)
Sound signal front LH
Input
Ignition
switch
ON
Voice output
37
(SB)
Ground
Mode change signal
Input
Ignition
switch
ON
Driver's Audio Stage ON
0 V
Driver's Audio Stage OFF
8.5 V
Terminal
(Wire color)
Description
Condition
Reference value
(Approx.)
+
–
Signal name
Input/
Output
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E
