WCS-84 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 139 (L) Ground Tire pressure receiv- Input/ Output Ignition switch Standby state When receiving the signal 140 (GR) Ground Selector lever P/N Input Selector lever P or N position 12.0 V Except P and N positions 0 V 141 (R) Ground Security indicator sig- Output Security indicator ON 0 V Blinking 11.3 V OFF Battery voltage 142 (BR) Ground Combination switch Output Combination All switch OFF 0 V Lighting switch 1ST 10.7 V Lighting switch HI Lighting switch 2ND Turn signal switch RH 143 (V) Ground Combination switch Output Combination All switch OFF 0 V Front wiper switch HI 10.7 V Any of the conditions below Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – OCC3881D OCC3880D JPMIA0014GB JPMIA0031GB JPMIA0032GB |
