WCS-72 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 39 (W) Ground Rear bumper anten- Output When the trunk When Intelligent Key is in When Intelligent Key is not 47 (Y) Ground Ignition relay (IPDM Output Ignition switch OFF or ACC Battery voltage ON 0 V 50 (R) Ground Trunk room lamp Input Trunk room lamp OFF (Trunk is closed) 11.8 V ON (Trunk is open) 0 V 52 (SB) Ground Starter relay control Output Ignition switch When the clutch pedal is Battery voltage When the clutch pedal is 0 V Ignition switch When selector lever is in P Battery voltage When selector lever is in P 0 V 61 (SB) Ground Trunk request switch Input Trunk request ON (Pressed) 0 V OFF (Not pressed) 1.0 V 64 (L) Ground Request switch buzz- Output Request switch Sounding 0 V Not sounding Battery voltage Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JMKIA0062GB JMKIA0063GB JPMIA0011GB JPMIA0016GB |
