PRECAUTIONS VTL-11 < PRECAUTION > C D E F G H J K L M A B VTL N O P CAUTION: The new and former refrigerant connections use different O-ring configurations. Never confuse O- O-Ring Part Numbers and Specifications F. Former type refrigerant connection N. New type refrigerant connection O. One-touch joint : O-ring size JSIIA0004ZZ Connection type Piping connection point Part number QTY O-ring size New Low-pressure flexible hose to low-pressure pipe 2 (One- 92473 N8221 2 16 High-pressure pipe 1 to high-pressure pipe 2 (One-touch 92471 N8221 2 8 Condenser pipe assembly to high-pressure flexible hose 92472 N8221 2 12 Condenser pipe assembly to high-pressure pipe 1 (One- 92471 N8221 2 8 Radiator & condenser assembly to condenser Inlet 92472 N8210 1 12 Outlet 92471 N8210 1 8 Low-pressure pipe 1 to low-pressure pipe 2 92473 N8210 1 16 Low-pressure pipe 1 to expansion valve 92473 N8210 1 16 High-pressure pipe 2 to expansion valve 92471 N8210 1 8 Compressor to low-pressure flexible hose 92474 N8210 1 19 Compressor to high-pressure flexible hose 92472 N8210 1 12 Liquid tank to radiator & condenser assembly Inlet 92471 N8210 1 8 Outlet 1 |
