PARK/NEUTRAL POSITION SWITCH

TM-9

< COMPONENT DIAGNOSIS >

[6MT: FS6R31A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

PARK/NEUTRAL POSITION SWITCH

Component Parts Location

INFOID:0000000001732860

Component Inspection

INFOID:0000000001732861

1.

CHECK PARK/NEUTRAL POSITION (PNP) SWITCH

Check continuity between park/neutral position (PNP) switch terminals with control lever turned to 1st to 6th
and reverse position.

Is the inspection result normal?

YES

>> INSPECTION END

NO

>> Replace park/neutral position (PNP) switch. Refer to

TM-29, "Exploded View"

.

PCIB1384E

Connector

Terminals

Gear position

Continuity

F55

1

2

Neutral

Existed

Except neutral

Not existed

TM-10

< SYMPTOM DIAGNOSIS >

[6MT: FS6R31A]

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000001732862

Use the chart below to help you find the cause of the symptom. The numbers indicate the order of the inspec-
tion. If necessary, repair or replace these parts.

Reference

TM-1

6

TM-2

9

TM-1

8

TM-2

9

TM-2

9

SUSPECTED PARTS
(Possible cause)

OIL

 (Oil

lev

e

l is

 lo

w

.)

OIL (W

rong oil.

)

OIL

 (Oil

lev

e

l is

 h

igh

.)

GASKET

 (Damaged)

OIL SEAL (W

orn or

damaged)

SHIFT CONTROL LINKAGE

(W

orn)

CHECK PLUG RETURN SPRING

 AND

CHECK BALL

(W

orn or damaged)

SHIF

T FORK (W

o

rn)

GEAR (W

o

rn o

r da

ma

ge

d)

BEARI

N

G (W

orn or

damaged)

BAUL

K

 RING (W

orn

 o

r da

ma

ge

d)

INSER

T SP

RING (Dam

ag

ed

)

Symptoms

Noise

1

2

3

3

Oil  leakage

3

1

2

2

Hard to shift or will not shift

1

1

2

2

2

Jumps  out  of  gear

1

1

2

2

PRECAUTIONS

TM-11

< PRECAUTION >

[6MT: FS6R31A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

PRECAUTION

PRECAUTIONS

Service Notice or Precautions for Manual Transmission

INFOID:0000000001732863

CAUTION:

• If transmission assembly is removed from the vehicle, always replace CSC (Concentric Slave Cylin-

der) body and CSC tube. Return CSC body insert to original position to remove transmission assem-
bly. Dust on clutch disc sliding parts may damage seal of CSC body and may cause clutch fluid
leakage.

• Never reuse transmission oil, once it has been drained.
• Check oil level or replace oil with vehicle on level ground.
• During removal or installation, keep inside of transmission clear of dust or dirt.
• Check for the correct installation status prior to removal or disassembly. If matching marks are

required, be certain they do not interfere with the function of the parts they are applied.

• In principle, tighten bolts or nuts gradually in several steps working diagonally from inside to out-

side. If tightening sequence is specified, observe it.

• Never damage sliding surfaces and mating surfaces.
• Never hold control lever housing to prevent bushing of control lever housing from deformation when

moving transmission assembly.

TM-12

< PREPARATION >

[6MT: FS6R31A]

PREPARATION

PREPARATION

PREPARATION

Special Service Tools

INFOID:0000000001732864

The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.

Tool number
(Kent-Moore No.)
Tool name

Description

KV381054S0
(J-34286)
Puller

Removing rear oil seal

ST33400001
(J-26082)
Drift
a: 60 mm (2.36 in) dia.
b: 47 mm (1.85 in) dia.

Installing rear oil seal

ST22490000
(

—

)

Adapter setting plate
a: 156 mm (6.14 in)
b: 220 mm (8.66 in)

Holding a adapter plate

ST33200000
(J-26082)
Drift
a: 60 mm (2.36 in) dia.
b: 44.5 mm (1.752 in) dia.

Installing counter rear bearing

KV32103300
(J-46529)
Press plate
a: 73 mm (2.87 in)

Installing reverse synchronizer assembly

ST01530000
(

—

)

Drift
a: 50 mm (1.97 in) dia.
b: 41 mm (1.61 in) dia.

Installing reverse synchronizer assembly

ZZA0601D

ZZA0814D

S-NT407

ZZA1002D

PCIB0165J

ZZA0534D
