BCM (BODY CONTROL MODULE) SEC-149 < ECU DIAGNOSIS > [INTELLIGENT KEY SYSTEM] C D E F G H I J L M A B SEC N O P 80 (GR) Ground NATS antenna amp Input/ Output During waiting Ignition switch is pressed Just after pressing ignition 81 (W) Ground NATS antenna amp Input/ Output During waiting Ignition switch is pressed Just after pressing ignition 82 (R) Ground Ignition relay [fuse Output Ignition switch OFF or ACC 0 V ON Battery voltage 83 (Y) Ground Remote keyless entry Input/ Output During waiting When operating either button on Intelligent Key 87 (BR) Ground Combination switch Input Combination All switch OFF 1.4 V Front fog lamp switch ON 1.3 V Any of the conditions below 1.3 V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JMKIA0064GB JMKIA0065GB JPMIA0041GB JPMIA0037GB JPMIA0040GB |
