DRIVER SEAT CONTROL UNIT

MIR-35

< ECU DIAGNOSIS >

[WITH ADP]

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

JCJWA0027GB

MIR-36

< ECU DIAGNOSIS >

[WITH ADP]

DRIVER SEAT CONTROL UNIT

JCJWA0028GB

DRIVER SEAT CONTROL UNIT

MIR-37

< ECU DIAGNOSIS >

[WITH ADP]

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

Fail Safe

INFOID:0000000000962334

The fail-safe mode may be activated if the following symptoms are observed.

JCJWA0029GB

MIR-38

< ECU DIAGNOSIS >

[WITH ADP]

DRIVER SEAT CONTROL UNIT

DTC Index

INFOID:0000000000962335

*1

:

• 0: Current malfunction is present

• 1-39: Displayed if any previous malfunction is present when current condition is normal. The numeral value increases by one at each

IGN ON to OFF cycle from 1 to 39. The counter remains at 39 even if the number of cycles exceeds it. However, the counter is reset
to 1 if any malfunction is detected again, the normal operation is resumed and the ignition switch is turned from OFF to ON.

Operating in

fail-safe mode

Malfunction Item

Related

DTC

Diagnosis

Only manual functions operate normally.

CAN communication

U1000

ADP-51

Tilt sensor

B2118

ADP-54

Telescopic sensor

B2119

ADP-57

Detent switch

B2126

ADP-60

Parking brake switch

B2127

ADP-62

Only manual functions, except door mirror, operate normally.

UART communication

B2128

ADP-64

Only manual functions, except seat sliding, operate normally.

Seat sliding output

B2112

ADP-52

Only manual functions, except seat reclining, operate normally.

Seat reclining output

B2113

ADP-52

CONSULT-III

display

Timing

*1

Item

Reference page

Current mal-

function

Previous mal-

function

CAN COMM CIRCUIT
[U1000]

0

1-39

CAN communication

ADP-51

SEAT SLIDE
[B2112]

0

1-39

Seat slide motor output

ADP-52

SEAT RECLINING
[B2113]

0

1-39

Seat reclining motor output

ADP-53

TILT SENSOR
[B2118]

0

1-39

Tilt sensor input

ADP-54

TELESCO SENSOR
[B2119]

0

1-39

Telescopic sensor input

ADP-57

DETENT SW
[B2126]

0

1-39

Detention switch condition

ADP-60

PARKING BRAKE
[B2127]

0

1-39

Parking brake switch condition

ADP-62

UART COMM
[B2128]

0

1-39

UART communication

ADP-64
