EXL-22 < FUNCTION DIAGNOSIS > [XENON TYPE] ACTIVE ADAPTIVE FRONT-LIGHTING SYSTEM Part Description AFS control unit Refer to Swivel actuator Refer to Aiming motor Refer to AFS switch Inputs AFS switch ON/OFF signal to AFS control unit. Height sensor Refer to Steering angle sensor Refer to IPDM E/R Transmits the headlamp (LO) ON signal and the headlamp (HI) ON signal to AFS control ECM Transmits the engine speed signal to AFS control unit with CAN communication. TCM Refer to Unified meter and A/C amp. Refer to Combination meter Turns AFS OFF indicator lamp ON/OFF/blinking according to AFS control unit request [with |
