EC-106 < FUNCTION DIAGNOSIS > [VQ35HR] ON BOARD DIAGNOSTIC (OBD) SYSTEM How to Display SRT Status WITH CONSULT-III Selecting “SRT STATUS” in “DTC CONFIRMATION” mode with CONSULT-III. WITH GST Selecting Service $01 with GST (Generic Scan Tool) NO TOOLS A SRT code itself can not be displayed while only SRT status can be. Turn ignition switch ON and wait 20 seconds. 2. SRT status is indicated as shown below. MALFUNCTION INDICATOR LAMP (MIL) Description The MIL is located on the combination meter. 1. The MIL will light up when the ignition switch is turned ON with- 2. When the engine is started, the MIL should go off. On Board Diagnostic System Function The on board diagnostic system has the following three functions. *1 “How to Read DTC and 1st Trip DTC” *2 “How to Display SRT Status” *3 “How to Set SRT Code” PBIB2317E SEF217U |
