Infiniti G35 (V35) Sedan. Manual - part 295

CCS

ICC SENSOR INTEGRATED UNIT

CCS-91

< ECU DIAGNOSIS >

[INTELLIGENT CRUISE CONTROL]

Fail Safe

INFOID:0000000000965474

When a malfunction occurs in ICC system, a chime sounds a beep, the system is released and ICC system
warning lamp in combination meter illuminates. System setting is not accepted when malfunction is detected.

DTC Index

INFOID:0000000000965475

: Applicable

JCOWA0005GB

CCS-92

< ECU DIAGNOSIS >

[INTELLIGENT CRUISE CONTROL]

ICC SENSOR INTEGRATED UNIT

DTC No.

CONSULT-III
screen terms

ICC

system

warning

lamp

Fail-safe

Reference page

CONSULT-III

On board

display

Vehicle-

to-

vehicle

distance

control

mode

Conven-

tional

(Fixed

speed)

cruise

control

mode

Brake as-

sist (With

preview

function)

C1A00

CONTROL UNIT

CCS-28

C1A01

POWER SUPPLY CIR 1

CCS-29

C1A02

POWER SUPPLY CIR 2

C1A03

VHCL SPEED SE CIRC

CCS-31

C1A04

ABS/TCS/VDC CIRC

CCS-33

C1A05

BRAKE SW/STOP L SW

CCS-35

C1A06

OPERATION SW CIRC

CCS-45

C1A12

LASER BEAM OFFCNTR

CCS-48

C1A13

STOP LAMP RLY FIX

CCS-49

C1A14

ECM CIRCUIT

CCS-56

C1A15

GEAR POSITION

CCS-58

C1A16

RADAR STAIN

CCS-60

C1A18

LASER AIMING INCMP

CCS-62

C1A21

UNIT HIGH TEMP

CCS-63

C1A24

NP RANGE

CCS-64

C1A26

ECD MODE MALF

CCS-66

C1A27

ECD PWR SUPLY CIR

CCS-68

NO DTC IS

DETECTED.

FURTHER

TESTING

MAY BE RE-

QUIRED.

NO DTC IS DETECTED.

FURTHER TESTING

MAY BE REQUIRED.

—

U1000

100

CAN COMM CIRCUIT

CCS-78

U1010

110

CONTROL UNIT (CAN)

CCS-79

U0121

127

VDC CAN CIR2

CCS-79

U0401

120

ECM CAN CIR1

CCS-79

U0402

122

TCM CAN CIR1

CCS-79

U0415

126

VDC CAN CIR1

CCS-79

CCS

INTELLIGENT CRUISE CONTROL SYSTEM SYMPTOMS

CCS-93

< SYMPTOM DIAGNOSIS >

[INTELLIGENT CRUISE CONTROL]

SYMPTOM DIAGNOSIS

INTELLIGENT CRUISE CONTROL SYSTEM SYMPTOMS

Symptom Table

INFOID:0000000000965476

Symptoms

Reference page

Operation

MAIN switch does not turn ON.

Symptom 1

CCS-94

MAIN switch does not switch OFF.

Cruise does not function for setting (powering functions).

Symptom 2

CCS-96

CANCEL switch does not function.

Symptom 3

CCS-98

Resume does not function.

Set speed does not increase.

Set distance to the vehicle ahead cannot be changed.

ICC is not cancelled when the A/T selector lever is “N”.

Symptom 4

CCS-99

Display/Chime

Multi information display not appear.

Check combination meter. Refer to

MWI-35, "Di-

agnosis Description"

Chime does not function.

Symptom 5

CCS-101

Control

Driving force is hunting.

Symptom 6

CCS-103

Function to detect
the vehicle ahead

System frequently cannot detect the vehicle ahead.

Symptom 7

CCS-104

Distance to detect the vehicle ahead is short.

System misidentifies a vehicle even though there is no vehicle
ahead.

• Adjust laser beam aiming. Refer to

CCS-7,

"LASER BEAM AIMING ADJUSTMENT : Spe-
cial Repair Requirement (Preparation)"

• Perform ICC action test. Refer to

CCS-11,

"ACTION TEST : Special Repair Requirement
(Vehicle-To-Vehicle Distance Control Mode)"

System misidentifies a vehicle in the next lane.

System does not detect a vehicle at all.

Symptom 8

CCS-105

CCS-94

< SYMPTOM DIAGNOSIS >

[INTELLIGENT CRUISE CONTROL]

MAIN SWITCH DOES NOT TURN ON, MAIN SWITCH DOES NOT TURN OFF

MAIN SWITCH DOES NOT TURN ON, MAIN SWITCH DOES NOT TURN
OFF

Description

INFOID:0000000000965477

MAIN SWITCH DOES NOT TURN ON

• ICC system display does not appear even when MAIN switch is pressed.

MAIN SWITCH DOES NOT TURN OFF

• When ICC system display is on, display does not turn off even if MAIN switch is pressed.
NOTE:
• When ICC system warning lamp is illuminated, ICC system is in fail-safe mode. where ICC system display

will not appear even if MAIN switch is pressed.

• Perform the self-diagnosis for ICC sensor integrated unit if ICC system warning lamp is illuminated. Repair

or replace applicable item.

Diagnosis Procedure

INFOID:0000000000965478

CHECK MAIN SWITCH

With COUSULT-III

Start engine.

With “DATA MONITOR” of “ICC”, check if “MAIN SW” and “CRUISE LAMP” operate normally.

Is the inspection result normal?

YES

>> GO TO 2.

>> GO TO 5.

CHECK UNIFIED METER AND A/C AMP.

With CONSULT-III

With “DATA MONITOR” of “METER”, check if “CRUISE IND” operate normally.

Is the inspection result normal?

YES

>> GO TO 3.

>> GO TO 5.

PERFORM SELF-DIAGNOSIS OF UNIFIED METER AND A/C AMP.

Perform self-diagnosis of unified meter and A/C amp.

Check if DTC is detected. Refer to

MWI-97, "DTC Index"

Is any DTC detected?

YES

>> Repair or replace applicable item.

>> GO TO 4

PERFROM SELF-DIAGNOSIS MODE OF COMBINATION METER

Perform self-diagnosis mode of combination meter. Refer to

MWI-35, "Diagnosis Description"

Check that the multi information display operates normally.

If it does not operate normally, repair the affected components or replace the combination meter.

>> INSPECTION END

PERFORM SELF-DIAGNOSIS OF ICC SENSOR INTEGRATED UNIT

Perform self-diagnosis of ICC sensor integrated unit.

Check if DTC “CAN COMM CIRCUIT [U1000]” (DTC 100) is detected.

Is it DTC detected?

YES

>> GO TO 6.

>> GO TO 7.

CAN COMMUNICATION INSPECTION

Perform CAN communication system inspection. Repair or replace the applicable item. Refer to

CCS-78,

"Diagnosis Procedure"
