TM-172

< COMPONENT DIAGNOSIS >

[5AT: RE5R05A]

SHIFT LOCK SYSTEM

JCDWA0006GB

SHIFT LOCK SYSTEM

TM-173

< COMPONENT DIAGNOSIS >

[5AT: RE5R05A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

JCDWA0007GB

TM-174

< COMPONENT DIAGNOSIS >

[5AT: RE5R05A]

SHIFT LOCK SYSTEM

Component Function Check

INFOID:0000000000957104

1.

CHECK A/T SHIFT LOCK OPERATION

1.

Turn ignition switch ON.

2.

Shift the selector lever to the “P” position.

3.

Attempt to shift the selector lever to any other position with the brake pedal released.

Can the selector lever be shifted to any other position?

JCDWA0008GB

SHIFT LOCK SYSTEM

TM-175

< COMPONENT DIAGNOSIS >

[5AT: RE5R05A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

YES

>> Go to

TM-175, "Diagnosis Procedure"

.

NO

>> GO TO 2.

2.

CHECK A/T SHIFT LOCK OPERATION

Attempt to shift the selector lever to any other position with the brake pedal depressed.

Can the selector lever be shifted to any other position?

YES

>> INSPECTION END

NO

>> Go to

TM-175, "Diagnosis Procedure"

.

Diagnosis Procedure

INFOID:0000000000957105

1.

CHECK SELECTOR LEVER POSITION

Check the selector lever position for damage. Refer to

TM-230, "2WD : Inspection and Adjustment"

 (2WD),

TM-230, "AWD : Inspection and Adjustment"

 (AWD)

Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Adjust control linkage. Refer to

TM-230, "2WD : Inspection and Adjustment"

 (2WD),

TM-230,

"AWD : Inspection and Adjustment"

 (AWD).

2.

CHECK POWER SOURCE

1.

Turn ignition switch OFF.

2.

Disconnect shift lock relay.

3.

Check voltage between shift lock relay harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 7.

NO-1

>> When pressing the brake pedal, the voltage is 0 V.: GO TO 2.

NO-2

>> When releasing the brake pedal, the voltage is battery voltage.: GO TO 5.

3.

CHECK POWER SOURCE

1.

Disconnect stop lamp switch harness connector.

2.

Check voltage between stop lamp switch harness connector and ground.

Is the inspection result normal?

YES

>> GO TO 4.

NO

>>

Check the following. If NG, repair or replace damaged parts.

• 10 A fuse [No. 7, located in the fuse block (J/B)]
• Harness for short or open between battery and stop lamp switch harness connector terminal 1

4.

CHECK STOP LAMP SWITCH

Check stop lamp switch. Refer to

TM-177, "Component Inspection (Stop lamp switch)"

.

Is the inspection result normal?

YES

>> Repair or replace harness connector between stop lamp switch and shift lock relay.

NO

>> Replace stop lamp switch. Refer to

BR-19, "Exploded View"

.

5.

CHECK STOP LAMP SWITCH

(+)

(

)

Condition

Voltage (Approx.)

Shift lock relay harness connector

Ground

Connector

Terminal

E52

2

Depressed brake pedal.

Battery voltage

Released brake pedal.

0 V

(+)

(

)

Voltage (Approx.)

Stop lamp switch harness connector

Ground

Connector

Terminal

E110

1

Battery voltage
