SYMPTOM DIAGNOSIS

SRS AIR BAG SYSTEM

Symptom Table

INFOID:0000000000959764

“SRS AIR BAG” Warning Lamp Does Not Turn OFF

1.

CHECK THE DEPLOYMENT OF AIR BAG MODULE

Check the air bag module.
Is “AIR BAG” module deployed?

YES

>> Refer to

SRC-178, "Diagnosis Procedure (Component diagnosis)"

.

NO

>> GO TO 2.

2.

CHECK THE AIR BAG FUSE

Refer to

PG-72, "Fuse"

.

Check 10A fuse [No.13, located in fuse block (J/B)].

OK

>> GO TO 4.

NG

>> GO TO 3.

3.

CHECK AIR BAG FUSE AGAIN

Replace “AIR BAG” fuse and turn ignition switch ON.

Does the “AIR BAG” fuse blow again?

YES

>> Repair or replace main harness.

NO

>> INSPECTION END

4.

CHECK DIAGNOSIS SENSOR UNIT

Check the diagnosis sensor unit.

Is “AIR BAG” displayed on CONSULT-lll?

YES

>> GO TO 5.

NO

>> Visually check the wiring harness connection of diagnosis sensor unit. If the harness connection

check result is OK, replace diagnosis sensor unit.

5.

CHECK HARNESS CONNECTION

Check the harness connection.

Is harness connections between warning lamp and diagnosis sensor unit?

OK

>> Replace diagnosis sensor unit.

NG

>> Connect “AIR BAG” warning lamp and diagnosis sensor unit connector properly. If “AIR BAG”

warning lamp still does not go off, replace harness.

“SRS AIR BAG” Warning Lamp Does Not Turn ON

1.

CHECK METER FUSE

Refer to

PG-72, "Fuse"

.

Check 10A fuse [No.14, located in fuse block (J/B)].

OK

>> GO TO 3.

NG

>> GO TO 2.

2.

CHECK METER FUSE AGAIN

Replace 10A fuse [No.14, located in fuse block (J/B)] and turn ignition switch ON.

Does the meter fuse blow again?

YES

>> Repair or replace the related harness.

NO

>> INSPECTION END
