AUTOMATIC DRIVE POSITIONER CONTROL UNIT

SE-107

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

K

L

M

A

B

SE

N

O

P

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

Removal and Installation

INFOID:0000000000960570

REMOVAL

CAUTION:

When removing and installing, use shop cloths to protect parts from damage.

1.

Remove the battery negative terminal.

2.

Remove the instrument driver lower panel. Refer to

IP-12,

"Removal and Installation"

.

3.

Remove the screws (A).

4.

Remove automatic drive positioner control unit (1).

INSTALLATION

Install in the reverse order of removal.

CAUTION:

• Clamp the harness in position.
NOTE:
After installing the driver seat, perform additional service when removing battery negative terminal. Refer to

ADP-8, "ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Description"

.

JMJIA0198ZZ

SE-108

< ON-VEHICLE REPAIR >

SEAT MEMORY SWITCH

SEAT MEMORY SWITCH

Removal and Installation

INFOID:0000000000960571

REMOVAL

CAUTION:

When removing and installing, use shop cloths to protect parts from damage.

1.

Disconnect battery negative terminal.

2.

Remove the front door finisher (1). Refer to

INT-10, "Removal

and Installation"

.

3.

Press pawls and remove seat memory switch (2) from front door
finisher (1).

INSTALLATION

Install in the reverse order of removal.

CAUTION:

• Clamp the harness in position.
NOTE:
After installing the driver seat, perform additional service when removing battery negative terminal. Refer to

ADP-8, "ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Description"

.

:

Pawl

JMJIA0197ZZ

POWER SEAT SWITCH

SE-109

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

K

L

M

A

B

SE

N

O

P

POWER SEAT SWITCH

Removal and Installation

INFOID:0000000000960572

REMOVAL

CAUTION:

When removing and installing, use shop cloths to protect parts from damage.

1.

Remove the seat cushion outer finisher (1). Refer to

SE-96,

"Disassembly and Assembly"

.

2.

Remove the screws (A).

3.

Remove the power seat switch (2) from the seat cushion outer
finisher (1).

INSTALLATION

Install in the reverse order of removal.

CAUTION:

• Clamp the harness in position.
NOTE:
After installing the driver seat, perform additional service when removing battery negative terminal. Refer to

ADP-8, "ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Description"

.

JMJIA0194ZZ

SE-110

< ON-VEHICLE REPAIR >

SIDE SUPPORT SWITCH

SIDE SUPPORT SWITCH

Removal and Installation

INFOID:0000000000960573

REMOVAL

CAUTION:

When removing and installing, use shop cloths to protect parts from damage.

1.

Remove the seat cushion outer finisher (1). Refer to

SE-95, "Removal and Installation"

.

2.

Remove the screws (A).

3.

Remove side support switch (2) from the seat cushion outer fin-
isher.

INSTALLATION

Install in the reverse order of removal.

CAUTION:

• Clamp the harness in position.
NOTE:
After installing the driver seat, perform additional service when removing battery negative terminal. Refer to

ADP-8, "ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Description"

.

JMJIA0192ZZ
