CHECK DOOR SWITCH

1. Disconnect door switch connector.
2. Check continuity between door switch terminals.

MTBL0384

SEL887VA

OK or NG

OK

©

Check the following.

I

Door switch ground circuit (Front) or door switch ground condition

I

Harness for open or short between control unit and door switch

NG

©

Replace door switch.

GI

MA

EM

LC

EC

FE

CL

MT

AT

AX

SU

BR

ST

RS

BT

HA

SC

IDX

MULTI-REMOTE CONTROL SYSTEM

Trouble Diagnoses (Cont’d)

EL-201

KEY SWITCH (INSERT) CHECK

=NCEL0115S07

1

CHECK KEY SWITCH INPUT SIGNAL

Check voltage between smart entrance control unit terminal 32 and ground.

SEL888V

Refer to wiring diagram in EL-194.

Voltage [V]:

Condition of key switch: Key is inserted.

Approx. 12

Condition of key switch: Key is withdrawn.

0

OK or NG

OK

©

Key switch is OK.

NG

©

GO TO 2.

2

CHECK KEY SWITCH (INSERT)

Check continuity between terminals 1 and 2.

SEL784V

Continuity:

Condition of key switch: Key is inserted.

Yes

Condition of key switch: Key is withdrawn.

No

OK or NG

OK

©

Check the following.

I

10A fuse [No. 24, located in fuse block (J/B)]

I

Harness for open or short between key switch and fuse

I

Harness for open or short between smart entrance control unit and key switch

NG

©

Replace key switch.

MULTI-REMOTE CONTROL SYSTEM

Trouble Diagnoses (Cont’d)

EL-202

DOOR LOCK/UNLOCK SWITCH CHECK

=NCEL0115S12

1

CHECK DOOR LOCK/UNLOCK SWITCH INPUT SIGNAL

1. Disconnect control unit connector.
2. Check continuity between control unit terminal 23 or 35 and ground.

MTBL0659

SEL875V

Refer to wiring diagram in EL-194.

OK or NG

OK

©

Door lock/unlock switch is OK.

NG

©

GO TO 2.

2

CHECK DOOR LOCK/UNLOCK SWITCH

1. Disconnect door lock/unlock switch connector.
2. Check continuity between each door lock/unlock switch terminals.

I

Power window main switch (Door lock/unlock switch)

SEL670W

OK or NG

OK

©

Check the following.

I

Ground circuit for door lock/unlock switch

I

Harness for open or short between door lock/unlock switch and smart entrance control
unit connector

NG

©

Replace door lock/unlock switch.

GI

MA

EM

LC

EC

FE

CL

MT

AT

AX

SU

BR

ST

RS

BT

HA

SC

IDX

MULTI-REMOTE CONTROL SYSTEM

Trouble Diagnoses (Cont’d)

EL-203

DOOR UNLOCK SENSOR CHECK

=NCEL0115S06

1

CHECK DOOR UNLOCK SENSOR INPUT SIGNAL

Check voltage between smart entrance control unit terminal 36 and ground.

SEL189X

Refer to wiring diagram in EL-194.

OK or NG

OK

©

Door unlock sensor (driver side) is OK.

NG

©

GO TO 2.

2

CHECK DOOR UNLOCK SENSOR

1. Disconnect door unlock sensor connector.
2. Check continuity between door unlock sensor (driver side) terminals.

SEL247VE

Continuity:

Condition: Locked

No

Condition: Unlocked

Yes

OK or NG

OK

©

Check the following.

I

Door unlock sensor ground circuit

I

Harness for open or short between smart entrance control unit and door unlock sensor
(driver side)

NG

©

Replace door unlock sensor (driver side).

MULTI-REMOTE CONTROL SYSTEM

Trouble Diagnoses (Cont’d)

EL-204
