Infiniti G20 (P11). Manual - part 21





3

CHECK SHIFT UP (D

2

TO D

3

)

Does A/T shift from D

2

to D

3

at the specified speed?

Read gear position, throttle position and vehicle speed.

Specified speed when shifting from D

2

to D

3

:

Refer to Shift schedule, AT-389.

SAT960I

Yes or No

Yes

©

GO TO 4.

No

©

Go to “10. A/T Does Not Shift: D

2

,

D

3

”, AT-246. Continue ROAD TEST.

4

CHECK SHIFT UP (D

3

TO D

4

) AND ENGINE BRAKE

Release accelerator pedal after shifting from D

2

to D

3

.

Does A/T shift from D

3

to D

4

and does vehicle decelerate by engine brake?

Read gear position, throttle position and vehicle speed.

SAT405H

Yes or No

Yes

©

1. Stop vehicle.
2. Go to “Cruise test — Part 3”, AT-82.

No

©

Go to “11. A/T Does Not Shift: D

3

,

D

4

”, AT-249. Continue ROAD TEST.

GI

MA

EM

LC

EC

FE

CL

MT

AX

SU

BR

ST

RS

BT

HA

SC

EL

IDX

TROUBLE DIAGNOSIS — BASIC INSPECTION

Road Test (Cont’d)

AT-81

Cruise Test — Part 3

=NCAT0028S0406

1

VEHICLE SPEED D

4

POSITION

1. Confirm overdrive control switch is in “ON” position.
2. Confirm selector lever is in “D” position.
3. Accelerate vehicle using half-throttle to D

4

.

SAT812A

©

GO TO 2.

2

CHECK SHIFT DOWN (D

4

TO D

3

)

1. Release accelerator pedal.

SAT813A

2. Set overdrive control switch to “OFF” position while driving in D

4

.

3. Does A/T shift from D

4

to D

3

(O/D OFF)?

Read gear position and vehicle speed.

SAT999I

Yes or No

Yes

©

GO TO 3.

No

©

Go to “17. A/T Does Not Shift: D

4

,

D

3

, When Overdrive Control Switch “ON”

,

“OFF”,

AT-260. Continue ROAD TEST.

TROUBLE DIAGNOSIS — BASIC INSPECTION

Road Test (Cont’d)

AT-82

3

CHECK ENGINE BRAKE

Does vehicle decelerate by engine brake?

SAT999I

Yes or No

Yes

©

GO TO 4.

No

©

Go to “15. Engine Speed Does Not Return To Idle (Light Braking D

4

,

D

3

)”, AT-257.

Continue ROAD TEST.

4

CHECK SHIFT DOWN (D

3

TO D

2

)

1. Move selector lever from “D” to “2” position while driving in D

3

(O/D OFF).

2. Does A/T shift from D

3

(O/D OFF) to 2

2

?

Read gear position.

SAT791GA

Yes or No

Yes

©

GO TO 5.

No

©

Go to “18. A/T Does Not Shift: D

3

,

D

2

, When Selector Lever “D”

,

“2” Position”,

AT-261. Continue ROAD TEST.

GI

MA

EM

LC

EC

FE

CL

MT

AX

SU

BR

ST

RS

BT

HA

SC

EL

IDX

TROUBLE DIAGNOSIS — BASIC INSPECTION

Road Test (Cont’d)

AT-83

5

CHECK ENGINE BRAKE

Does vehicle decelerate by engine brake?

SAT791GA

Yes or No

Yes

©

GO TO 6.

No

©

Go to “15. Engine Speed Does Not Return To Idle (Light Braking D

4

,

D

3

)”, AT-257.

Continue ROAD TEST.

6

CHECK SHIFT DOWN

1. Move selector lever from “2” to “1” position while driving in 2

2

.

2. Does A/T shift from 2

2

to 1

1

position?

Read gear position.

SAT778B

Yes or No

Yes

©

GO TO 7.

No

©

Go to “19. A/T Does Not Shift: 2

2

,

1

1

, When Selector lever “2”

,

“1” Position”, AT-262.

Continue ROAD TEST.

TROUBLE DIAGNOSIS — BASIC INSPECTION

Road Test (Cont’d)

AT-84
