AUTO LIGHT SYSTEM

LT-51

< SERVICE INFORMATION >

C

D

E

F

G

H

I

J

L

M

A

B

LT

N

O

P

TKWM4298E

LT-52

< SERVICE INFORMATION >

AUTO LIGHT SYSTEM

Terminal and Reference Value for BCM

INFOID:0000000001328313

CAUTION:

• Check combination switch system terminal waveform under the loaded condition with lighting

switch, turn signal switch and wiper switch OFF not to be fluctuated by overloaded.

• Turn wiper intermittent dial position to 4 except when checking waveform or voltage of wiper inter-

mittent dial position. Wiper intermittent dial position can be confirmed on CONSULT-III. Refer to

LT-

103, "CONSULT-III Functions (BCM)"

.

TKWM4299E

AUTO LIGHT SYSTEM

LT-53

< SERVICE INFORMATION >

C

D

E

F

G

H

I

J

L

M

A

B

LT

N

O

P

Terminal

No.

Wire

color

Signal name

Measuring condition

Reference value

Ignition

switch

Operation or condition

4

Pu/W

Combination switch in-
put 3

ON

Lighting, turn, wiper
switch
(Wiper intermittent
dial position 4)

OFF

Approx. 0 V

Lighting switch
AUTO

Approx. 1.0 V

11

LG

Ignition switch (ACC)

ACC

Battery voltage

12

P/B

Front door switch
(Passenger side) signal

OFF

Front door switch
(Passenger side)

ON (open)

Approx. 0 V

OFF (closed)

Approx. 7.5 - 8.0 V

13

P/L

Rear door switch RH
signal

OFF

Rear door switch RH
(Personal lamp RH
ON or OFF position)

ON (open)

Approx. 0 V

OFF (closed)

Battery voltage

14

P

Optical sensor signal

ON

When optical sensor is illuminated

3.1 V or more

Note

When optical sensor is not illuminated

0.6 V or less

17

Y/G

Optical sensor power
supply

ON

Approx. 5 V

18

B

Sensor ground

ON

Approx. 0 V

33

G

Combination switch
output 4

ON

Lighting, turn, wiper
switch
(Wiper intermittent
dial position 4)

OFF

Approx. 7.2 V

Lighting switch
AUTO

Approx. 1.2 V

38

W/L

Ignition switch (ON)

ON

Battery voltage

39

L

CAN



H

40

P

CAN



L

42

L/R

Battery power supply

OFF

Battery voltage

PKIB4959J

SKIB3419J

PKIB4960J

PKIB4958J

LT-54

< SERVICE INFORMATION >

AUTO LIGHT SYSTEM

NOTE:

Optical sensor must be securely subjected to work lamp light. If optical sensor is insufficiently illuminated, the measured value may not
satisfy standard.

Terminal and Reference Value for IPDM E/R

INFOID:0000000001328314

How to Proceed with Trouble Diagnosis

INFOID:0000000001328315

1.

Confirm the symptom or customer complaint.

2.

Understand operation description and function description. Refer to

LT-47, "System Description"

.

3.

Perform Preliminary Check. Refer to

LT-55, "Preliminary Check"

.

4.

Check symptom and repair or replace the cause of malfunction. Refer to

LT-58, "Symptom Chart"

.

49

B

Ground

ON

Approx. 0 V

52

B

Ground

ON

Approx. 0 V

55

G

Battery power supply

OFF

Battery voltage

58

L

Back door switch signal

OFF

Back door closure
motor (door switch)

ON (open)

Approx. 0 V

OFF (closed)

Battery voltage

62

W

Front door switch
(Driver side) signal

OFF

Front door switch
(Driver side)

ON (open)

Approx. 0 V

OFF (closed)

Approx. 7.0 - 7.5 V

63

P

Rear door switch LH
signal

OFF

Rear door switch LH

ON (open)

Approx. 0 V

OFF (closed)

Battery voltage

Terminal

No.

Wire

color

Signal name

Measuring condition

Reference value

Ignition

switch

Operation or condition

PKIB4960J

Terminal

No.

Wire

color

Signal name

Measuring condition

Reference value

Ignition

switch

Operation or condition

20

LG

Headlamp low (RH)

ON

Lighting switch 2ND
position

OFF

Approx. 0 V

ON

Battery voltage

22

R

Parking, license plate, side
marker and tail lamps

ON

Lighting switch 1ST po-
sition

OFF

Approx. 0 V

ON

Battery voltage

27

BR

Headlamp high (RH)

ON

Lighting switch HIGH
or PASS position

OFF

Approx. 0 V

ON

Battery voltage

28

SB

Headlamp high (LH)

ON

Lighting switch HIGH
or PASS position

OFF

Approx. 0 V

ON

Battery voltage

30

GY

Headlamp low (LH)

ON

Lighting switch 2ND
position

OFF

Approx. 0 V

ON

Battery voltage

38

B

Ground

ON

Approx. 0 V

48

L

CAN



H

49

R

CAN



L

60

B

Ground

ON

Approx. 0 V
