EXL-184 < SYMPTOM DIAGNOSIS > [XENON TYPE] PARKING, LICENSE PLATE AND TAIL LAMPS ARE NOT TURNED ON PARKING, LICENSE PLATE AND TAIL LAMPS ARE NOT TURNED ON Description INFOID:0000000003135385 The parking, license plate, tail, side marker lamps and each illumination are not turned ON in any condition. Diagnosis Procedure INFOID:0000000003135386 1. COMBINATION SWITCH INSPECTION Check the combination switch. Refer to Is the combination switch normal? YES >> GO TO 2. NO >> Repair or replace the malfunctioning part. 2. CHECK TAIL LAMP RELAY REQUEST SIGNAL INPUT CONSULT-III DATA MONITOR 1. Select "TAIL & CLR REQ" of IPDM E/R data monitor item. 2. With operating the lighting switch, check the monitor status. Is the item status normal? YES >> GO TO 3. NO >> Replace BCM. 3. TAIL LAMP CIRCUIT INSPECTION Check the tail lamp circuit. Refer to EXL-86, "Component Function Check" Is the tail lamp circuit normal? YES >> Replace IPDM E/R. NO >> Repair or replace the malfunctioning part. Monitor item Condition Monitor status TAIL & CLR Lighting switch 1ST On OFF Off |
