EXL-156 < ECU DIAGNOSIS > [XENON TYPE] IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) ST/INHI RLY Ignition switch ON Off At engine cranking INHI → ST The status of starter relay or starter control relay cannot be recognized by UNKWN DETENT SW Ignition switch ON • Press the selector button with se- lector lever in P position • Selector lever in any position oth- er than P Off Release the selector button with selector lever in P position On S/L RLY -REQ None of the conditions below are present Off • Open the driver door after the ignition switch is turned OFF (for a few seconds) • Press the push-button ignition switch when the steering lock is activat- ed On S/L STATE Steering lock is activated LOCK Steering lock is deactivated UNLOCK [DTC: B210A] is detected UNKWN DTRL REQ NOTE: Off OIL P SW Ignition switch OFF, ACC or engine running Open Ignition switch ON Close HOOD SW Close the hood Off Open the hood On HL WASHER REQ NOTE: Off THFT HRN REQ Not operation Off • Panic alarm is activated TEM On HORN CHIRP Not operating Off Door locking with Intelligent Key (horn chirp mode) On CRNRNG LMP REQ NOTE: Off Monitor Item Condition Value/Status |
