CHG-12 < COMPONENT DIAGNOSIS > L TERMINAL CIRCUIT (OPEN) 2. Check voltage between combination meter harness connector and ground. Is the inspection result normal? YES >> Replace combination meter. NO >> Inspect the power supply circuit. Refer to PG-51, "Wiring Diagram - IGNITION POWER SUPPLY - Terminals Condition Voltage (Approx.) (+) (–) Combination meter harness connector Terminal M53 21 Ground When the ignition switch is in ON position Battery voltage |
