LANE CAMERA UNIT

JCOWM0031GB

CCS

LANE CAMERA UNIT

CCS-173

< ECU DIAGNOSIS >

[LDW & LDP]

C

D

E

F

G

H

I

J

K

L

M

B

N

P

A

Fail-safe

INFOID:0000000003514633

FAIL-SAFE CONTROL BY DTC

When any DTC is detected, the LDW/LDP systems do not operate.

TEMPORARY DISABLED STATUS AT HIGH TEMPERATURE

When using LDW

JCOWM0032GB

CCS-174

< ECU DIAGNOSIS >

[LDW & LDP]

LANE CAMERA UNIT

• If the vehicle is parked in direct sunlight under high temperature conditions [approximately over 104

°

F

(40

°

C)] and then started, the system may sound a buzzer and cancel automatically. In this case LDW ON

indicator will blink.

• When the interior temperature is reduced, LDW ON indicator is turned ON.

When using LDP

• If the vehicle is parked in direct sunlight under high temperature conditions [approximately over 104

°

F

(40

°

C)] and then started, the system may sound a buzzer and cancel automatically. In this case LDP ON

indicator lamp will blink.

• When the interior temperature is reduced, LDP ON indicator lamp is turned ON.

DTC Inspection Priority Chart

INFOID:0000000003514634

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.

DTC Index

INFOID:0000000003514635

×

: Applicable

Priority

Detected items (DTC)

1

• U1000: CAN COMM CIRCUIT
• U1010: CONTROL UNIT (CAN)

2

• U0122: VDC CAN CIR1(LDP)
• U0416: VDC CAN CIR2(LDP)

3

C1B00: CAMERA UNIT MALF

4

• C1B01: CAM AIMING INCMP
• C1B02: VHCL SPD DATA MALF
• C1B03: ABNRML TEMP DETECT
• C1B07: ABS DIAGNOSIS

DTC

Lane departure

warning lamp

LDW ON indicator

LDP ON indicator

lamp

Fail-safe

Reference

page

C1B00

CAMERA UNIT MALF

ON

—

—

×

CCS-138

C1B01

CAM AIMING INCMP

Blink

—

—

×

CCS-139

C1B02

VHCL SPD DATA MALF

ON

—

—

×

CCS-140

C1B03

ABNRML TEMP DETECT

—

Blink

(When using LDW)

Blink

(When using LDP)

×

CCS-141

C1B07

ABS DIAGNOSIS

ON

—

—

×

CCS-142

U1000

CAN COMM CIRCUIT

ON

—

—

×

CCS-143

U1010

CONTROL UNIT (CAN)

ON

—

—

×

CCS-144

U0122

VDC CAN CIR1 (LDP)

ON

—

—

×

CCS-145

U0416

VDC CAN CIR2 (LDP)

ON

—

—

×

CCS-147
