ON-VEHICLE REPAIR

POWER SOCKET

FRONT POWER SOCKET

FRONT POWER SOCKET : Exploded View

INFOID:0000000003523693

FRONT POWER SOCKET : Removal and Installation

INFOID:0000000003523694

REMOVAL

1.

Remove the console finisher assembly. Refer to

IP-22, "Removal and Installation"

.

2.

Disconnect the power socket connector (A).

3.

Pull out the inner socket (1) by pushing the ring pawl (B) from
the inner socket hole (square) (C).

4.

Remove the ring (2) from the console finisher assembly while
pressing pawls.

INSTALLATION

Install in the reverse order of removal.
NOTE:
Align the inner socket, the ring and the console finisher assembly cut out.

CONSOLE POWER SOCKET

CONSOLE POWER SOCKET : Exploded View

INFOID:0000000003131869

CONSOLE POWER SOCKET : Removal and Installation

INFOID:0000000003131870

REMOVAL

1

: Inner socket

2

:  Ring

JPMIA0920ZZ

D

: Cut out

JPMIA0921ZZ

1

: Inner socket

2

:  Ring

JPMIA0893ZZ

PWO-6

< ON-VEHICLE REPAIR >

POWER SOCKET

1.

Remove the console finisher. Refer to

IP-22, "Removal and Installation"

.

2.

Disconnect the power socket connector (A).

3.

Pull out the inner socket (1) by pushing the ring pawl (B) from
the inner socket hole (square) (C).

4.

Remove the ring (2) from the console finisher while pressing
pawls.

INSTALLATION

Install in the reverse order of removal.
NOTE:
Align the inner socket, the ring and the console finisher cut out.

D

: Cut out

JPMIA0894ZZ



2008 EX35 – Engine





VQ35HR






Tune Up Information:

MA – 6



Engine Information:

EM – 139



Engine Electrical - Starting:

STR – 18



  Charging:

CHG – 31





PREPARATION


Make sure that the following parts are in order.

1. Battery
2. Ignition system
3.  Engine oil and coolant levels (Oil filler cap, oil level, etc.)
4. Fuse
5.  ECM harness connector
6. Vacuum hoses
7.  Air intake system
8. Fuel pressure
9. Engine compression
10. Throttle  valve
11. Evaporative emission canister purge control valve.


Note:

•  On A/C equipped vehicles, turn A/C "Off" for testing.

•  Transmission should be in "Park" or "Neutral".

•  "CO" probe should be inserted into exhaust approximately 16 inches.

•  Turn off headlamps, heater blower, rear defogger, etc.

•  Front wheels pointed straight.

•  Perform inspection with cooling fans "Off".
