PWC-56 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 78 (Y) Ground Room antenna ( − ) (Instrument panel) Output Ignition switch When Intelligent Key is in When Intelligent Key is not 79 (BR) Ground Room antenna (+) Output Ignition switch When Intelligent Key is in When Intelligent Key is not 80 (GR) Ground NATS antenna amp Input/ Output During waiting Ignition switch is pressed Just after pressing ignition 81 (W) Ground NATS antenna amp Input/ Output During waiting Ignition switch is pressed Just after pressing ignition 82 (R) Ground Ignition relay [Fuse Output Ignition switch OFF or ACC 0 V ON Battery voltage Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output + – JMKIA0062GB JMKIA0063GB JMKIA0062GB JMKIA0063GB |
