MWI-82

< ECU DIAGNOSIS >

COMBINATION METER

JCNWM0715GB

MWI

COMBINATION METER

MWI-83

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

Fail-Safe

INFOID:0000000003140231

FAIL-SAFE

Combination meter performs fail-safe operation when unified meter and A/C amp. communication is malfunc-
tion.
Solution for communication error between the unified meter and A/C amp. and combination meter.

JCNWM0716GB

MWI-84

< ECU DIAGNOSIS >

COMBINATION METER

DTC Index

INFOID:0000000003140232

Refer to

MWI-101, "DTC Index"

.

Function

Specifications

Speedometer

Reset to zero by suspending communication.

Tachometer

Fuel gauge

Water temperature gauge

Illumination control

When suspending communication, change to nighttime mode.

Information display

The display turns off by suspending communication.

Buzzer

The buzzer turns off by suspending communication.

Warning lamp/indicator
lamp

ABS warning lamp

The lamp turns on by suspending communication.

VDC OFF indicator lamp

SLIP indicator lamp

Brake warning lamp

CRUISE warning lamp

High beam indicator

The lamp turns off by suspending communication.

Turn signal indicator lamp

Light indicator lamp

Oil pressure warning lamp

Malfunction indicator lamp

A/T CHECK warning lamp

AWD warning lamp

Low tire pressure warning lamp

Key warning lamp

AFS OFF indicator lamp

Lane departure warning lamp

LDP ON indicator lamp

Master warning lamp

MWI

UNIFIED METER AND A/C AMP.

MWI-85

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

UNIFIED METER AND A/C AMP.

Reference Value

INFOID:0000000003140233

VALUES ON THE DIAGNOSIS TOOL

CONSULT-III MONITOR ITEM

Monitor Item

Condition

Value/Status

SPEED METER
[km/h]

Ignition switch
ON

While driving

Equivalent to speedometer reading
NOTE:
655.35 is displayed when the malfunc-
tion signal is received

SPEED OUTPUT
[km/h]

Ignition switch
ON

While driving

Equivalent to speedometer reading
NOTE:
655.35 is displayed when the malfunc-
tion signal is received

ODO OUTPUT
[km/h] or [mph]

Ignition switch
ON

—

Equivalent to odometer reading in
combination meter

TACHO METER
[rpm]

Ignition switch
ON

While driving

Equivalent to tachometer reading
NOTE:
8191.875 is displayed when the mal-
function signal is received

FUEL METER
[lit.]

Ignition switch
ON

—

Values according to fuel level

W TEMP METER
[

°

C]

Ignition switch
ON

—

Values according to engine coolant
temperature
NOTE:
215 is displayed when the malfunction
signal is input

ABS W/L

Ignition switch
ON

ABS warning lamp ON

On

ABS warning lamp OFF

Off

VDC/TCS IND

Ignition switch
ON

VDC OFF indicator lamp ON

On

VDC OFF indicator lamp OFF

Off

SLIP IND

Ignition switch
ON

SLIP indicator lamp ON

On

SLIP indicator lamp OFF

Off

BRAKE W/L

Ignition switch
ON

Brake warning lamp ON

On

Brake warning lamp OFF

Off

DOOR W/L

Ignition switch
ON

Door warning displayed

On

Door warning not displayed

Off

HI-BEAM IND

Ignition switch
ON

Hi-beam indicator lamp ON

On

Hi-beam indicator lamp OFF

Off

TURN IND

Ignition switch
ON

Turn indicator lamp ON

On

Turn indicator lamp OFF

Off

FR FOG IND

Ignition switch
ON

NOTE:
This item is displayed, but cannot be moni-
tored.

Off

RR FOG IND

Ignition switch
ON

NOTE:
This item is displayed, but cannot be moni-
tored.

Off

LIGHT IND

Ignition switch
ON

Light indicator lamp ON

On

Light indicator lamp OFF

Off

OIL W/L

Ignition switch
ON

Oil pressure warning lamp ON

On

Oil pressure warning lamp OFF

Off
