Honda Ridgeline. Manual - part 542





*05

*06

*07

Save Users Memory

23-134

Navigation System

System Diagnostic Mode (cont’d)

Return

EXPORT

IMPORT

Save Users Memory

Return

Yes

No

Return

Yes

No

Save Users Memory

Export User Data

Save Users Memory

Import User Data

When replacing the navigation unit, this function allows
the dealer to transfer the customer’s personal data to
the new navigation unit. The transferred information
includes their Setup settings, and personal addresses.
The dealer inserts a PC card to the navigation unit, and
then selects the ‘‘Save Users Memory’’ function. The
two functions in this diagnostic screen are EXPORT and
IMPORT. EXPORT saves the customer’s data to the PC
card, and IMPORT moves the PC card files to the new
navigation unit.

Before starting this function, see the PC Card FAQs for
information regarding PC cards, and the use of this
function.

1. Select EXPORT button to move the client’s data

from the original navigation unit to the PC card.
Select ‘‘YES’’ on the ‘‘Export User Data’’
Confirmation screen. The process takes only a
couple of seconds. The system stores two files on
the card.

NOTE: If the EXPORT button is grayed out, check
the PC card’s edge connector, and the pins inside
the navigation unit (with a flashlight) for damage.

2. After installing the customer’s original DVD in the

new navigation unit, allow the system to boot up.
Insert the PC card in the new navigation unit and
enter the ‘‘Save Users Memory’’ in the navigation
system diagnostic mode.

3. Select IMPORT button to move the two files stored

by the Export process from the PC card to the new
navigation unit. Select ‘‘YES’’ on the ‘‘Import User
Data’’ Confirmation screen. When the transfer is
finished (a few seconds) the system will
automatically reboot. After the system reboots,
remove the PC card from the PC slot.

NOTE: If the IMPORT button is grayed out, check if
the ‘‘Model’’ and the ‘‘Program Flash’’ shown on
the ‘‘Version’’ screen are the same.

PC Card FAQs

Question

Answer

23-135

Where do we buy the flash memory or
adaptors, and what do we ask for?

You need a ‘‘PCMCIA type II’’ adaptor and a flash memory chip. They can
be purchased at a computer, or office supply store. The card will have
the same size and shape as the PC card in the HDS. Adaptors that accept
multiple flash types are not recommended.

What memory flash chips will work
with what adaptors?

The flash memory devices that have been tested include Compact Flash
(CF), and ATA style (like the card in the HDS). Other card types and flash
memory chips may work, but have not been tested.

What capacity card do I need for this
function?

A memory chip with capacity of 64 MB to 2 GB will work. The two files
moved to the PC card during ‘‘export’’ are less than a Megabyte in size.

Should the dealer have a dedicated PC
card for the Export and Import
navigation function?

Yes, treat the PC card as a dedicated ‘‘special tool’’ that should be used
anytime your ’07 or later customer needs their navigation personal files
transferred to a new navigation unit.

What device can I use to maintain the
PC card, and delete files?

Any computer store sells USB style card readers that accept the PC card,
and allow you to perform file maintenance on your PC card. Most laptops
will also accept the PC card.

Can we move the customer’s data to
different models?

No, the files are model specific and will only load into a navigation unit
with the same part number.

Can we move the customer’s data to
the same vehicle with a different
software version?

The client’s files can only be transferred to a new navigation unit, if the
‘‘Model’’ and the ‘‘Program Flash’’ shown on the ‘‘Version’’ screen are
the same. Files cannot be transferred to the different model and different
versions.

Will other files on the PC card like
images or music files prevent the
Export/Import function from working?

No, the system simply adds two small files that are recognized by the
new navigation unit when performing the import function. However, it
the PC card is full, the ‘‘Export’’ function won’t work correctly.

Do I have to delete the files on the PC
card after each transfer of the
customer’s data?

After the transfer of customer data to the new navigation unit, the files
remain on the PC card. Since this is confidential information, we
recommend that you delete these files after each use. Please note that
each time you export navigation files of the same model and version, the
files are overwritten. If you do not delete the files after use, over time the
PC card will accumulate two files for each version of the 8 or so Honda
navigation models.

What format should be used if the PC
card needs reformatting?

It is unlikely that the PC card will ever need formatting, however the FAT
file system should be used.

I can’t enter the navigation diagnostic
mode to do the Export/Import function.
How can I transfer the client’s data?

Some internal navigation unit ECU failures may make it impossible to
use the Export/Import function.

(cont’d)

Question

Answer

23-136

Navigation System

System Diagnostic Mode (cont’d)

Why wont the Export or Import
functions work? What do I check as
part of troubleshooting?

The card may not be fully inserted into the slot. Eject the PC card, and
inspect for warping or damage to the edge connector. Never use
excessive force to insert a PC card. This can result in damage to the
pins in the rear of the slot.
The PC card may not contain files that are recognized by the new
navigation unit. Navigation data can only be transferred between
navigation units with the same ‘‘Model code’’, and with the same
navigation ‘‘Program flash’’ version.
The flash memory chip type may not be accepted by the system. Only
Compact Flash and ATA cards have been tested.
The card’s PCMCIA adaptor may be preventing a known-good PC card
from playing. Avoid multi slot type PCMCIA adaptors that accept
several different flash memory types.
The card may be full and as a result the files are stored, but without
any data. Export and import appear to function, but move nothing.
Delete unused files from the PC card.
There may not be any files on the PC card. If the PC card has a ‘‘write
protection’’ switch, make sure it is turned off before attempting to use
the Export function.
Although flash memory chips are reliable, occasionally they develop
bad sectors or other formatting errors that prevents them from
accepting files. The PC card should be reformatted using the FAT
format.
The PC card may have been formatted using the format ‘‘NTFS’’. Only
the ‘‘FAT’’ format is accepted by the system.
Hard Disc Drive (HDD) cards may not work properly in the system and
can overheat or quit functioning, particularly in a hot vehicle. They are
not recommended.
Before performing the Import function, ensure that the client’s original
DVD is loaded into the new navigation unit and working properly.

Error Message Table

Screen Error Message

Solution

23-137

Navigation system is unable to acquire a proper
GPS signal.

Make sure there is nothing on the dashboard blocking the GPS
antenna. If not, move the vehicle to an open space away from
tall buildings, trees, etc. After-market devices can affect the
GPS reception.

Navigation unit door is open or No DVD disc
installed. Please check system.

Make sure the correct white-labeled navigation DVD is
installed with the label side up and the navigation unit door is
snapped fully closed (see page 23-138).

No DVD disc, please check system.

Display temp is too high. System will shut down
until display cools down.

Outside temperature is low, system will take a
while to start up.

Route has not been completed. Please try again
from a different location.

No alternate route found. Original route will be
guided.
This destination cannot be found in database.

Please operate climate control after starting
engine.

DVD disc reading error (unformatted), please
consult your dealer.

Check that the navigation DVD is installed with the label side
up (see page 23-138).
This message will appear briefly when the display
temperature is too high, and the display will turn off until the
temperature cools down. The system will turn back on when
the display cools down.
The temperature is below −30 °C and the navigation ECU has
difficulties reading the DVD. The system will start up when the
temperature warms up.
Check the DVD source for scratches or other damage. Make
sure you are using an official Honda navigation DVD (white in

database. Try planning a different route to or from a different
location.
No alternate route method was found. The original route will
be used.
The destination was not found in the database. Try another
destination nearby, or select the destination with the joystick.
The engine needs to be running to operate the climate control
system.

video DVDs. If the problem persists, see your dealer. Check

Routing to or from a place (new area) that is not in the

any official Honda service website for more service information

color). The system cannot read other mapping databases or

about prescribing patches for the navigation system.
