22-224
Power Windows
Back Power Window Position Switch Test
A
B
1. Remove the rear panel trim (see page 20-69).
2. Disconnect the 2P connector (A) from the back
power window position switch (B).
3. Check for continuity between the terminals.
• There should be continuity between the No. 1
and No. 2 terminals when the back power
window middle glass is opened.
• There should not be continuity between the No. 1
and No. 2 terminals when the back power
window is closed.
4. If the continuity is not as specified, replace the
switch.
