04 05 01 20-118 Seats Rear Seat Removal/Installation (cont’d) Fastener Locations : Clip, 2 A E C D C D B A A Fastener Locations : Bolt, 6 B C B B A 10 x 1.25 mm 4. From both sides, pull out the rear seat mount covers (A) to detach the clips, then remove the 5. Remove the head restraint (A). From both sides of the rear trim panel (B), detach the hooks (C) and 6. Remove the right rear seat belt buckle and center seat belt buckle (see page 24-11). 7. Remove the center seat belt lower anchor bolt (see step 2 on page 24-9) and left rear seat belt buckle 8. Pull out the center seat belt through the gap between the rear seat-back and rear seat cushion 9. Remove the rear seat assembly (A). –1 Remove the bolts. (B) from the holes (C) on the body, then |
