03 04 05 06 20-18 Doors Rear Door Latch Replacement (cont’d) Fastener Locations : Screw, 2 C : Screw, 1 D A B C D E D C C C 6 x 1.0 mm Inside A B C D Fastener Location : Screw, 1 A B A A B 6. Disconnect the actuator connectors (A), and detach the inner handle cable clip (B). Remove the screws 7. Remove the latch (A) with the protector through the hole in the door. Take care not to bend the outer 8. Remove the screw and release the hooks (A), then remove the latch protector (B). 9. Disconnect the inner handle cable (A) and lock cable (B). 10. Install the latch in the reverse order of removal, and note these items: • Make sure the actuator connectors are plugged in properly and that the cables and each rod are • Make sure the door locks and opens properly. plastic cover is installed properly and sealed |
