*01 *02 − − − − YES NO YES NO 14-161 PCM CONNECTOR C (44P) SHIFT SOLENOID SH A SH A SH A (RED) SHIFT SOLENOID SHIFT SOLENOID 13. Disconnect the shift solenoid harness connector. 14. Check for continuity between PCM connector terminal C25 and shift solenoid harness connector Go to step 15. Repair open in the wire between PCM connector terminal C25 and the shift solenoid 15. Remove the shift solenoid harness (see page 14-188). 16. Check for continuity between shift solenoid harness connector terminal No. 4 and the shift Replace shift solenoid valve A (see page 14-188), then go to step 17. Replace the shift solenoid harness (see page 14-188), then go to step 17. (cont’d) Wire side of Terminal side of Wire side of Terminal side of Is ther e continuity? Is ther e continuity? |
