− − − − − − − − YES NO YES NO YES NO YES NO 14-153 13. Replace A/T clutch pressure control solenoid valve C (see page 14-203). 14. Reconnect all connectors. 15. Turn the ignition switch to ON (II). 16. Clear the DTC with the HDS. 17. Start the engine, and wait for at least 1 second. 18. Check for Temporary DTCs or DTCs with the HDS. Check for poor connections or loose terminals at A/T clutch pressure control solenoid If Temporary DTC or DTC P0970 is not indicated, or if any other Temporary DTCs are 19. Monitor the OBD STATUS for P0970 in the DTCs MENU with the HDS. Troubleshooting is complete. If any other Temporary DTC or DTCs were indicated on step 18, If the screen indicates FAILED, check for poor connections or loose terminals at A/T clutch 20. Update the PCM if it does not have the latest software (see page 14-8), or substitute a known- 21. Start the engine, and wait for at least 1 second. 22. Check for Temporary DTCs or DTCs with the HDS. Check for poor connections or loose terminals at A/T clutch pressure control solenoid If Temporary DTC or DTC P0970 is not indicated, or if any other Temporary DTCs or DTCs 23. Monitor the OBD STATUS for P0970 in the DTCs MENU with the HDS. If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the If the screen indicates FAILED, check for poor connections or loose terminals at A/T clutch Is DT C P097 0 indicated? Does the scr een indicate PASSED? Is DT C P097 0 indicated? Does the scr een indicate PASSED? |
