Vehicle Lift
Safety Stands
Floor Jack
1-10
General Information
Lift and Support Points
A
B
C
A
C
B
C
NOTE: If you are going to remove heavy components
such as suspension or the fuel tank from the rear of the
vehicle, first support the front of the vehicle with tall
safety stands. When substantial weight is removed
from the rear of the vehicle, the center of gravity can
change, causing the vehicle to tip forward on the lift.
1. Position the lift blocks (A) under the vehicle’s front
support points (B) and rear support points (C).
2. Raise the lift a few inches, and rock the vehicle
gently to be sure it’s firmly supported.
3. Raise the lift to its height, and inspect the vehicle
support points for solid contact with the lift blocks.
To support the vehicle on safety stands, use the same
support points (B and C) as for a vehicle lift. Always use
safety stands when working on or under any vehicle
that is supported only by a jack.
1. When lifting the front of the vehicle, set the parking
brake. When lifting the rear of the vehicle, put the
shift lever in the P position.
2. Block the wheels that are not being lifted.
3. Position the floor jack under the front jacking
bracket (A) or the rear jacking bracket (B). Center
the jacking bracket on the jack lift platform (C), and
jack up the vehicle high enough to fit the safety
stands under it.
4. Position the safety stands under the support points
and adjust them so the vehicle is level.
5. Lower the vehicle onto the stands.
