Honda Odyssey 2004. Manual - part 590





*03

04

05

06

YES

NO

YES

NO

23-302

SRS

DTC Troubleshooting (cont’d)

C505

YEL/GRN

BLK

A

14. Disconnect dashboard wire harness A 21P

connector C505 from the right side wire harness.

15. Turn the ignition switch ON (II).

16.

Open in the YEL/GRN wire of the right side

wire harness; replace the right side wire harness.

Open in the YEL/GRN wire of the dashboard

wire harness; replace the faulty harness.

17. Turn the ignition switch OFF.

18. Check resistance between the No. 6 terminal of the

ground. There should be 0

1.0

.

Go to step 19.

Open in the BLK wire of the right side wire

harness; check for poor ground connection at G851.
If the connection is OK, replace the right side wire
harness.

19. Turn the ignition switch OFF. Disconnect the

battery negative cable, and wait for 3 minutes.

20. Disconnect both seat belt tensioner 2P connectors

(A).

Wire side of female terminals

Is ther e batter y voltage?

Is the r esistance as specif ied?

03/07/29 10:41:00 61S0X050_230_0302

Check for voltage between the No. 4 terminal of
dashboard wire harness A 21P connector C505 and
body ground. There should be battery voltage.

DASHBOARD WIRE HARNESS A 21P CONNECTOR C505

right side wire harness 6P connector C and body

Wire side of female terminals

RIGHT SIDE WIRE HARNESS 6P CONNECTOR C

07

08

09

YES

NO

YES

NO

23-303

B

SRS UNIT CONNECTOR B (28P)

BLU

RIGHT SIDE WIRE HARNESS

SRS UNIT
CONNECTOR B (28P)

BLU

BLU

21. Disconnect SRS unit connector B (28P) from the

SRS unit, and OPDS unit connector D (8P) from the
OPDS unit.

22. Check resistance between the No. 27 terminal of

SRS unit connector B (28P) and body ground. There
should be an open circuit, or at least 1 M

.

Go to step 23.

Go to step 30.

23. Check resistance between the No. 27 terminal of

SRS unit connector B (28P) and the No. 5 terminal

should be 0

1.0

.

Faulty front passenger’s weight sensors unit

or SRS unit; replace the front passenger’s weight
sensors unit (see page 23-391). If the problem is
still present, replace the SRS unit
(see page 23-391).

Go to step 24.

(cont’d)

Wire side of female terminals

Wire side of female terminals

Is the r esistance as specif ied?

Is the r esistance as specif ied?

03/07/29 10:41:00 61S0X050_230_0303

of the right side wire harness 6P connector C. There

6P CONNECTOR C

*04

11

*05

13

YES

NO

YES

NO

23-304

SRS

DTC Troubleshooting (cont’d)

C505

SRS UNIT CONNECTOR B (28P)

DASHBOARD WIRE HARNESS A

BLU

BLU

C503

SRS UNIT CONNECTOR B (28P)

SRS MAIN HARNESS
8P CONNECTOR C503

BLU

BLU

24. Disconnect dashboard wire harness A 21P

connector C505 from the right side wire harness.

25.

0

1.0

.

Open in the BLU wire of the right side wire

harness; replace the right side wire harness.

Go to step 26.

26. Disconnect SRS main harness 8P connector C503

from dashboard wire harness A.

27. Check resistance between the No. 27 terminal of

SRS unit connector B (28P) and the No. 1 terminal
of SRS main harness 8P connector C503. There
should be 0

1.0

.

Open in the BLU wire of dashboard wire

harness A; replace dashboard wire harness A.

Go to step 28.

Wire side of female terminals

Wire side of female terminals

Wire side of female terminals

Wire side of female terminals

Is the r esistance as specif ied?

Is the r esistance as specif ied?

03/07/29 10:41:01 61S0X050_230_0304

Check resistance between the No. 27 terminal of
SRS unit connector B (28P) and the No. 2 terminal
of dashboard wire harness A 21P connector C505.
There should be

21P CONNECTOR C505

*06

15

*07

17

YES

NO

YES

NO

23-305

C851

A

SRS UNIT CONNECTOR B (28P)

SRS FLOOR HARNESS
28P CONNECTOR C851

BLU

BLU

C505

SRS UNIT CONNECTOR B (28P)

BLU

28. Disconnect SRS floor harness 28P connector (A)

from the SRS main harness connector C851.

29. Check resistance between the No. 27 terminal of

SRS unit connector B (28P) and the No. 16 terminal
of SRS floor harness 28P connector C851. There
should be 0

1.0

.

Open in the BLU wire of the SRS main

harness; replace the SRS main harness.

Open in the BLU wire of the SRS floor

harness; replace the SRS floor harness.

30. Disconnect dashboard wire harness A 21P

connector C505 from the right side wire harness.

31. Check resistance between the No. 27 terminal of

SRS unit connector B (28P) and body ground. There
should be an open circuit, or at least 1 M

.

Short to ground in the right side wire

harness; replace the right side wire harness.

Go to step 32.

(cont’d)

Wire side of female terminals

Terminal side of male terminals

Wire side of female terminals

Is the r esistance as specif ied?

Is the r esistance as specif ied?

03/07/29 10:41:02 61S0X050_230_0305
