Honda Odyssey 2004. Manual - part 534





02

02

04

YES

NO

YES

NO

23-78

SRS

DTC Troubleshooting (cont’d)

B

A

A

SRS MAIN HARNESS 18P CONNECTOR

6. Reconnect the battery negative cable.

7. Erase the DTC memory.

8. Read the DTC (see page 23-35).

Go to step 9.

Short in the front passenger’s airbag inflator;

replace the front passenger’s airbag (see page 23-
370).

9. Turn the ignition switch OFF. Disconnect the

battery negative cable, and wait for 3 minutes.

10. Disconnect the driver’s airbag 2P connector (A) and

both seat belt tensioner 2P connectors (B).

11. Disconnect the special tool (2

) from the SRS main

harness 2P connector.

12. Disconnect the SRS main harness 18P connector

(A) from the SRS unit.

13. Check resistance between the No. 10 and No. 14

terminals of the SRS main harness 18P connector.
There should be an open circuit, or at least 1 M

.

Faulty SRS unit; replace the SRS unit (see

page 23-382).

Short to another wire in the SRS main

harness; replace the SRS main harness.

Wire side of female terminals

Is DT C 2-3 indicated?

Is the r esistance as specif ied?

03/07/29 10:33:02 61S0X050_230_0078

01

02

S0X4AZ4K79100081024FAAT00

’99-01 Models

DTC 2-4:

YES

NO

YES

NO

23-79

07TAZ-SZ5011A

07SAZ-TB4011A

A

B

A

Short to Power in Front Passenger’s

Airbag Inflator

1. Erase the DTC memory (see page 23-38).

2. Turn the ignition switch ON (II), and check that the

SRS indicator comes on for about 6 seconds and
then goes off.

Go to step 3.

Intermittent failure, system is OK at this time.

Go to Troubleshooting Intermittent Failures (see
page 23-39).

3. Turn the ignition switch OFF. Disconnect the

battery negative cable, and wait for 3 minutes.

4. Disconnect the front passenger’s airbag 2P

connector from the SRS main harness 2P connector
(A).

5. Connect the special tool (2

connector) to the SRS

main harness 2P connector.

6. Reconnect the battery negative cable.

7. Erase the DTC memory.

8. Read the DTC (see page 23-35).

Go to step 9.

Short to power in the front passenger’s airbag

inflator; replace the front passenger’s airbag (see
page 23-370).

9. Turn the ignition switch OFF. Disconnect the

battery negative cable, and wait for 3 minutes.

10. Disconnect the driver’s airbag 2P connector (A) and

both seat belt tensioner 2P connectors (B), and
disconnect the special tool from the SRS main
harness 2P connector.

(cont’d)

Does the SRS indicator stay on?

Is DT C 2-4 indicated?

03/07/29 10:33:02 61S0X050_230_0079

02

04

01

S0X4AZ4K79100081025FAAT00

YES

NO

YES

NO

’99-01 Models

DTC 2-5:

23-80

23-80

SRS

DTC Troubleshooting (cont’d)

A

SRS MAIN HARNESS 18P CONNECTOR

07TAZ-SZ5011A

07SAZ-TB4011A

A

11. Disconnect the SRS main harness 18P connector

(A) from the SRS unit.

12. Reconnect the battery negative cable.

13. Turn the ignition switch ON (II).

14. Check for voltage between the No. 10 terminal of

the SRS main harness 18P connector and body
ground, and between the No. 14 terminal and body
ground. There should be 0.5 V or less.

Faulty SRS unit; replace the SRS unit (see

page 23-382).

Short to power in the SRS main harness;

replace the SRS main harness.

1. Erase the DTC memory (see page 23-38).

2. Turn the ignition switch ON (II), and check that the

SRS indicator comes on for about 6 seconds and
then goes off.

Go to step 3.

Intermittent failure, system is OK at this time.

Go to Troubleshooting Intermittent Failures (see
page 23-39).

3. Disconnect the battery negative cable, and wait for

3 minutes.

4. Disconnect the front passenger’s airbag 2P

connector from the SRS main harness 2P connector
(A).

5. Connect the special tool (2

connector) to the SRS

main harness 2P connector.

Short to Ground in Front Passenger’s

Airbag Inflator

Wire side of female terminals

Is the voltage as specif ied?

Does the SRS indicator stay on?

03/07/29 10:33:03 61S0X050_230_0080

02

01

04

YES

NO

YES

NO

23-81

B

A

A

SRS MAIN HARNESS 18P CONNECTOR

6. Reconnect the battery negative cable.

7. Erase the DTC memory.

8. Read the DTC (see page 23-35).

Go to step 9.

Short to ground in the front passenger’s

airbag inflator; replace the front passenger’s airbag
(see page 23-370).

9. Turn the ignition switch OFF. Disconnect the

battery negative cable, and wait for 3 minutes.

10. Disconnect the driver’s airbag 2P connector (A) and

both seat belt tensioner 2P connectors (B), and
disconnect the special tool from the SRS main
harness 2P connector.

11. Disconnect the SRS main harness 18P connector

(A) from the SRS unit.

12. Check resistance between the No. 10 terminal of

the SRS main harness 18P connector and body
ground, and between the No. 14 terminal and body
ground. There should be an open circuit, or at least
1 M

.

Faulty SRS unit; replace the SRS unit (see

page 23-382).

Short to ground in the SRS main harness;

replace the SRS main harness.

Wire side of female terminals

Is DT C 2-5 indicated?

Is the r esistance as specif ied?

03/07/29 10:33:04 61S0X050_230_0081
