Honda Odyssey 2004. Manual - part 458





*01

S0X4A00J10311113151CAAT01

*01

S0X4A00J10311149551FEAT02

Audio Unit Connector Inputs and Outputs

Cavity

Wire

Connect to

Position

Resistance

(SEEK)

(VOL.UP)

(VOL.DOWN)

22-160

22-160

Audio System

System Description

Radio Remote Switch Test

B

A

C

When replacing an audio unit connector, match the
wires to the cavities listed in the following table. Cavity
1 is not used.

2

WHT/RED

ACC (main stereo power
supply)

3

GRN/RED

Radio remote switch

4

BLU

Security input

5

RED/YEL

Right rear speaker (

)

6

BLU/YEL

Left rear speaker (

)

7

RED/GRN

Front passenger’s speaker
(

)

Right tweeter (

)

8

BLU/GRN

Driver’s door speaker (

)

Left tweeter (

)

9

RED/BLK

Lights-on signal

10

WHT/BLU

Constant power

11

ORN

Navigation unit

12

BLU/GRN

Navigation unit

13

ORN/BLU

Navigation unit

14

WHT/BLK

Navigation unit

15

BRN/WHT

Right rear speaker (

)

16

GRY/WHT

Left rear speaker (

)

17

BRN/BLK

Front passenger’s door
speaker (

)

Right tweeter (

)

18

GRY/BLK

Driver’s door speaker (

)

Left tweeter (

)

19

RED

Dash lights brightness
controller

20

BLK

Ground (G502)

: With security alarm system

1. Remove the two screws (A) from the radio remote

switch (B).

2. Remove the radio remote switch from the steering

wheel and disconnect the 2P connector (C).

3. Measure resistance between the No. 1 and No. 2

terminals in each switch position according to the
table.

OFF

Approx. 3.6 k

Approx. 990

Approx. 370

Approx. 100

4. If the resistance is not as specifide, replace the

remote switch.

03/07/29 10:22:35 61S0X050_220_0162

03

*01

01

02

S0X4A00J10370327201KBAT00

Door

Tweeter

Rear

’99-01 models:

’02-04 models:

22-161

Speaker Replacement

C

A

B

A

B

C

A

B

C

A

B

1. Remove the front door panel (see page 20-7).

2. Remove the speaker cover (A).

3. Remove the three screws, then disconnect the 2P

connector (B) from the speaker (C).

Carefully pry the tweeter (A) out of the dashboard, then
disconnect the 2P connector (B) from the tweeter.

1. Remove the speaker cover (A).

2. Remove the two (or three) screws, then disconnect

the 2P connector (B) from the speaker (C).

03/07/29 10:22:35 61S0X050_220_0163

01

01

S0X4A00J10311000000KBAT00

Special Tools Required

22-162

Audio System

Mast Antenna Replacement

A

3 N·m (0.3 kgf·m,
2.1 lbf·ft)

B

C

D

B
2.3 N·m (0.23 kgf·m,
1.7 lbf·ft)

07XAA-0010200

B

A

Antenna nut wrench 07XAA-0010200

1. Remove the antenna mast (A).

2. Remove the antenna nut (B), spacer (C) and

bushing (D).

3. Remove the right inner fender (see page 20-149).

4. Remove the antenna housing bracket bolt (A), then

pull the housing out of the wheel well.

5. If necessary, remove the two bolts (B) from the

housing, then separate the housing from the
bracket.

03/07/29 10:22:36 61S0X050_220_0164

*01

S0X4A00J54211500000EAAT10

22-163

Accessory Power Sockets

Circuit Diagram

WHT/RED

BLK

G501

WHT/RED

No.9
(15A)

G552

BLK

BLK

G581

WHT/RED

YEL

YEL/BLK

(7.5A)

No.8

WHT/BLK

ACC

BAT

WHT

No.42
(50A)

(40A)

No.54

No.41
(120A)

BATTERY

UNDER HOOD
FUSE/RELAY
BOX

IGNITION
SWITCH

DRIVER’S
UNDER DASH
FUSE/RELAY
BOX

ACCESSORY
POWER
SOCKET
RELAY

PASSENGER’S
UNDER DASH
FUSE/RELAY
BOX

FRONT
ACCESSORY
POWER
SOCKET

REAR
ACCESSORY
POWER
SOCKET

DVD UNIT (’02 04 models)

AUDIO UNIT
A/T GEAR POSITION
INDICATOR (’02 04 models)

REAR CONTROLLER
and SCREEN (’02 04 models)

03/07/29 10:22:36 61S0X050_220_0165
