22-92
Ignition Switch
Replacement
A
B
SRS components are located in this area. Review the
SRS component locations, ’99-01 models (see page 23-
18), ’02 model (see page 23-19), ’03-04 models (see
page 23-20), and the precautions and procedures (see
page 23-21) in the SRS before performing repairs or
service.
1. Make sure you have the anti-theft codes for the
radio and the navigation system, then write down
the frequencies for the radio’s preset buttons.
2. Disconnect the battery negative cable.
3. Remove the steering column covers (see page 17-
25).
4. Insert the ignition key, and turn it to ‘‘0’’.
5. Remove the two screws (A), and replace the
electrical switch (B).
6. Install in the reverse order of removal.
7. After reconnecting the battery, enter the anti-theft
codes for the radio and the navigation system, then
enter the customer’s radio station presets.
8. Do the power window control unit reset procedure
(see page 22-200).
9. Confirm that all systems work properly.
