Honda Odyssey 2004. Manual - part 440





01

02

03

04

S0X4A00J54460647111FEAT00

Relay

Test

type 1:

type 2:

type 3:

Normally-open type A

22-88

Relays

Power Relay Test

2

3

1

4

1

2

3

4

1

2

4

3

1

2

4

3

Use this chart to identify the type of relay, then do the
test listed for it.
NOTE: For the turn signal/hazard relay input test (see
page 22-136).

Accessory power socket
relay

Normally-open
type A

A/C compressor clutch
relay
Condenser fan relay
Fail-safe relay
Headlight relay 1
Headlight relay 2
Horn relay
Interior lights relay
Low beam cut relay
(Canada)
Power window relay
Radiator fan relay
Reverse relay
Rear A/C blower low relay
Rear A/C blower middle
relay
Seat heater relay
Starter cut relay
Taillight relay
TCS relay
ABS pump motor relay

Normally-open
type B

Blower motor relay
Blower motor high relay
Rear A/C blower high relay
Rear window defogger
relay
Rear A/C blower main relay

Five-terminal
type A

Daytime running lights
relay (Canada)

Five-terminal
type B

Fuel fill door relay
Left rear window motor
close relay
Left rear window motor
open relay
Radiator fan control relay
Rear A/C mode and motor
relay
Right rear window motor
close relay
Right rear window motor
open relay
Windshield wiper
intermittent relay

Check for continuity between the terminals.

• There should be continuity between the No. 1 and

No. 2 terminals when power and ground are
connected to the No. 3 and No. 4 terminals.

• There should be no continuity between the No. 1 and

No. 2 terminals when power is disconnected.

03/07/29 10:19:56 61S0X050_220_0090

*01

06

07

08

09

10

Normally-open type B

Blower motor relay, type 1:

Blower motor relay, type 2:

ABS pump motor relay:

Rear A/C blower high relay:

Rear window defogger relay:

22-89

1

2

3

4

3

4

2

1

1

2

3

4

3

4

2

1

1

2

3

4

1

2

3

4

Check for continuity between the terminals.

• There should be continuity between the No. 1 and

No. 3 terminals when power and ground are
connected to the No. 2 and No. 4 terminals.

• There should be no continuity between the No. 1 and

No. 3 terminals when power is disconnected.

(cont’d)

03/07/29 10:19:57 61S0X050_220_0091

*02

12

*03

*04

Five-terminal type A

Five-terminal type B

Rear A/C blower main relay:

22-90

Relays

Power Relay Test (cont’d)

1

2

3

4

5

1

2

3

4

5

1

2

3

4

5

1

2

3

4

5

Check for continuity between the terminals.

• There should be continuity between the No. 1 and

No. 2 terminals when power and ground are
connected to the No. 3 and No. 5 terminals.

• There should be continuity between the No. 2 and

No. 4 terminals when power is disconnected.

Check for continuity between the terminals.

• There should be continuity between the No. 1 and

No. 2 terminals when power and ground are
connected to the No. 3 and No. 5 terminals.

• There should be continuity between the No. 1 and

No. 4 terminals when power is disconnected.

03/07/29 10:19:58 61S0X050_220_0092

01

*01

S0X4A00J54200034401FEAT00

22-91

Ignition Switch

Test

BLK/YEL

YEL

WHT/BLK

WHT

BLK/WHT

Terminal

Position

O (LOCK)

I (ACC)

II (ON)

III (START)

WHT/

BLK

(ACC)

WHT
(BAT)

BLK/

YEL

(IG1)

YEL

(IG2)

BLK/
WHT
(ST)

SRS components are located in this area. Review the
SRS component locations, ’99-01 models (see page 23-
18), ’02 model (see page 23-19), ’03-04 models (see
page 23-20), and the precautions and procedures (see
page 23-21) in the SRS before performing repairs or
service.

1. Make sure you have the anti-theft codes for the

radio and the navigation system, then write down
the frequencies for the radio’s preset buttons.

2. Disconnect the battery negative cable.

3. Remove the dashboard lower cover (see page 20-

69).

4. Disconnect the 6P connector from the driver’s

under-dash fuse/relay box.

5. Check for continuity between the terminals in each

switch position according to the table.

6. If the continuity checks do not agree with the table,

replace the electrical switch.

7. After reconnecting the battery, enter the anti-theft

codes for the radio and the navigation system, then
enter the customer’s radio station presets.

8. Do the power window control unit reset procedure

(see page 22-200).

9. Confirm that all systems work properly.

Wire side of female terminals

03/07/29 10:19:59 61S0X050_220_0093
