Symptom

Diagnostic procedure

Also check for

19-46

ABS Components

Symptom Troubleshooting Index

ABS indicator does not come on

ABS Indicator Circuit Troubleshooting (see page
19-73)

ABS indicator does not go off, and no
DTCs are stored

ABS Indicator Circuit Troubleshooting (see page
19-73)

Brake system indicator does not come
on

Brake System Indicator Circuit Troubleshooting
(see page 19-75)

Brake system indicator does not go off
and no DTCs are stored

Brake System Indicator Circuit Troubleshooting
(see page 19-75)

03/07/29 09:54:19 61S0X050_190_0046

−

−

−

―――

−

−

−

−

−

―――

−

−

−

−

−

１１

Ｓ０Ｘ４Ａ０７Ｄ１０６００００００００ＣＡＡＴ１０

ABS Control Unit Inputs and Outputs for Connector B (12P)

Terminal

number

Terminal sign

(Terminal

name)

Terminal

Wire

color

Description

Measurement

Conditions

(Ignition switch ON (II))

Voltage

19-47

System Description

ABS CONTROL UNIT CONNECTOR B (12P)

1

BLU/
WHT

WALP

(Warning

lamp)

Drives ABS indicator
light
(Turns the indicator
light drive transistor
to ON, then turns off
the indicator light)

1

ON

4

6 V

OFF

Below 0.3 V

2

BLK

GND1

(Ground 1)

Ground

2

Below 0.3 V

3

YEL/

WHT

RR-OUT

(Rear-right

outlet)

Drives right-rear
outlet solenoid valve

3

OFF

Battery
Voltage

4

YEL/

BLU

FL-OUT

(Front-left

outlet)

Drives left-front
outlet solenoid valve

4

5

YEL/

GRN

RL-OUT

(Rear-left

outlet)

Drives left-rear outlet
solenoid valve

5

ON

(Disconnect

connector

A to turn light on)

Below 0.3 V

6

YEL/

BLK

FR-OUT

(Front-right

outlet)

Drives right-front
outlet solenoid valve

6

7

BLK

GND2

(Ground 2)

Ground

7

Below 0.3 V

8

RED/
WHT

RR-IN

(Rear-right

inlet)

Drives right-rear inlet
solenoid valve

8

OFF

Battery
Voltage

9

RED/

BLU

FL-IN

(Front-left

inlet)

Drives left-front inlet
solenoid valve

9

10

RED/

GRN

RL-IN

(Rear-left

inlet)

Drives left-rear inlet
solenoid valve

10

ON

(Disconnect

connector

A to turn light on)

Below 0.3 V

11

RED/

BLK

FR-IN

(Front-right

inlet)

Drives right-front
inlet solenoid valve

11

12

YEL/

RED

PMR

(Pump

motor relay)

Drives pump motor
relay

12

OFF

Pump

motor

ON

Below 1.0 V

OFF

Battery
Voltage

ON

Below 0.3 V

(cont’d)

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

ABS
indicator

ABS
indicator

ABS
indicator

ABS
indicator

Wire side of female terminals

03/07/29 09:54:20 61S0X050_190_0047

−

―――

−

−

−

＋

−

−

＋

−

−

−

１２

ABS Control Unit Inputs and Outputs for Connector A (22P)
