Honda Odyssey 2004. Manual - part 251





01

S0X4AA1E10410700000EAAT00

14-398

A/T Gear Position Indicator

Circuit Diagram

B2

RELAY

RED/BLK

BLU/BLK

BLK

G503

DIMMING
CIRCUIT

P

GAUGE ASSEMBLY

R

N

D

2

1

CIRCUIT

SPEEDOMETER

D

WHT

YEL

YEL

YEL

WHT

BOX

DRIVER’S

FUSE/RELAY BOX

(DRIVER’S)

UNIT

CONTROL

MULTIPLEX

UNDER DASH
FUSE/RELAY

CUT

STARTER

B14

BLU/WHT

NP

ATP

BRN

BLU

RED

BLU/BLK

WHT

RED/BLK

RED

BLU

BRN

BLU/WHT

VSS

A9

OUT

BLU/YEL

E

ST

A

No.9 (10A)

IG1

BAT

CONTROL

YEL

IND

R

1

2

UNIT

CRUISE

BLK

G101

RED/WHT

PNK

GRY

BLK/BLU

WHT

RED

YEL

GRN

BLU

BRN

BRN

BLU

RED

RED/BLK

WHT

BLK/BLU

GRN/BLK

BRN

BLU

RED

YEL

WHT

POWERTRAIN CONTROL MODULE (PCM)

UNDER DASH

IGNITION SWITCH

No.41 (120A)

D

D3

D5

ATP

D9

ATP

D15

D

UNDER HOOD FUSE/RELAY BOX

D14

D8

D6

A14

ATP

ATP

ATP

D5

TRANSMISSION RANGE SWITCH

1

2

N

R

P

BATTERY

No.42 (50A)

B16

B11

C12

C15

C4

C16

C6

C7

C5

C13

P

3

2

1

4

5

6

7

8

9

10

3

5

3

03/07/29 09:45:26 61S0X050_140_0401

*01

01

S0X4AA1E10410719021FAAT00

YES

NO

YES

NO

YES

NO

YES

NO

14-399

D Indicator Circuit Troubleshooting

PCM CONNECTOR A (32P)

D5 IND (GRN/BLK)

PCM CONNECTOR D (16P)

ATP D5 (YEL)

1. Turn the ignition switch ON (II), and watch the D

indicator.

Go to step 2.

If the indicator comes on for about 2 seconds

and then goes off, it’s OK. If it doesn’t come on at
all, go to step 13.

2. Make sure the HDS is not connected to the data link

connector.

3. Turn the ignition switch OFF.

4. Disconnect PCM connector A (32P).

5. Turn the ignition switch ON (II).

6. Measure the voltage between PCM connector

terminal A14 terminal and body ground.

Repair short to power in the wire between

PCM connector terminal A14 and the gauge
assembly.

Go to step 7.

7. Turn the ignition switch OFF.

8. Reconnect PCM connector A (32P).

9. Turn the ignition switch ON (II).

10. Shift to any position other than D.

11. Measure the voltage between PCM connector

terminal D9 and body ground.

Faulty PCM or gauge assembly.

Check for a short to ground in the wire

between PCM connector terminal D9 and the
transmission range switch. If the wire is OK, check
the transmission range switch.

12. Turn the ignition switch ON (II).

13. Shift to the D position.

Check for loose terminal fit in the PCM

connector A14 and recheck the D indicator several
times. If the problem is intermittent, substitute a
known-good PCM and recheck. If the indicator then
works OK every time, replace the original PCM.

Go to step 14.

14. Turn the ignition switch OFF.

(cont’d)

Wire side of female terminals

Wire side of female terminals

Does the D indicator come on and stay on?

Is ther e voltage?

Is ther e voltage?

Does the D indicator come on?

03/07/29 09:45:26 61S0X050_140_0402

*02

*03

*04

YES

NO

YES

NO

YES

NO

14-400

A/T Gear Position Indicator

D Indicator Circuit Troubleshooting (cont’d)

PCM CONNECTOR B (25P)

LG2 (BRN/YEL)

LG1 (BRN/YEL)

PCM CONNECTOR B (25P)

IGP1 (YEL/BLK)

IGP2 (YEL/BLK)

LG1 (BRN/YEL)

LG2 (BRN/YEL)

PCM CONNECTORS

A (32P)

LG2 (BRN/YEL)

LG1 (BRN/YEL)

D5 IND (GRN/BLK)

B (25P)

15. Disconnect PCM connector B (25P).

16. Check for continuity between PCM connector

terminals B20 and body ground, and between B22
and body ground.

Go to step 17.

Repair open in the wire(s) between PCM

connector terminal B20, B22, and ground (G101), or
repair poor ground (G101).

17. Turn the ignition switch ON (II).

18. Measure the voltage between PCM connector

terminals B1 and B22, and between B9 and B20.

Go to step 19.

Repair open or short in the wire between PCM

connector terminal B1 or B9 and the PGM-FI main
relay.

19. Turn the ignition switch OFF.

20. Reconnect PCM connector B (25P).

21. Connect the digital multimeter between PCM

connector terminals A14 and B20 or B22.

22. Turn the ignition switch ON (II).

Check for an open in the wire between PCM

connector terminal A14 and the gauge assembly. If
the wire is OK, check for a faulty D indicator bulb or
a faulty printed circuit board in the gauge
assembly.

Go to step 23.

Wire side of female terminals

Wire side of female terminals

Wire side of female terminals

Is ther e continuity between gr ound and each
ter minal?

Is ther e batter y voltage?

Is ther e voltage f or at least 2 seconds?

03/07/29 09:45:27 61S0X050_140_0403

02

YES

NO

14-401

PCM CONNECTOR A (32P)

D5 IND (GRN/BLK)

23. Turn the ignition switch OFF.

24. Disconnect PCM connector A (32P).

25. Check for continuity between PCM connector

terminal A14 and body ground.

Repair open in the wire between PCM

connector terminal A14 and the gauge assembly.

Check for loose terminal fit in the PCM

connectors. Check the transmission range switch. If
necessary, substitute a known-good PCM and
recheck.

Wire side of female terminals

Is ther e continuity?

03/07/29 09:45:27 61S0X050_140_0404
