Honda Odyssey 2004. Manual - part 62





*10

01

*11

Clearance: 0.2

0.7 mm (0.01

0.03 in.)

7-26

Engine Block

Crankshaft and Piston Installation (cont’d)

07749-0010000

070AD-RCA0200

0.2

0.7 mm

(0.01

0.03 in.)

A

C

B

6 x 1.0 mm
12 N·m (1.2 kgf·m, 8.7 lbf·ft)

22.

23. Drive the crankshaft oil seal squarely into the

engine block end cover.

24. Confirm that the clearance is equal all the way

around with a feeler gauge.

25. Clean and dry the engine block end cover mating

surfaces.

26. Apply liquid gasket, P/N 08718-0001 or 08718-0003,

evenly to the block mating surface of the engine
block end cover and to the inner threads of the bolt
holes. Install the dowel pins (A), new O-ring (B) and
the left side cover (C) on the cylinder block.

NOTE: Do not install the parts if 4 minutes or more
have elapsed since applying the liquid gasket.
Instead, reapply liquid gasket after removing the
old residue.

27. After assembly, wait at least 30 minutes before

filling the engine with oil.

03/07/29 09:13:10 61S0X050_070_0026

The seal mating surface on the engine block end
cover should be dry. Apply a light coat of multi-
purpose grease to the crankshaft and to the lip of
the seal.

02

*14

7-27

6 x 1.0 mm
12 N·m (1.2 kgf·m, 8.7 lbf·ft)

6 x 1.0 mm
12 N·m (1.2 kgf·m,
8.7 lbf·ft)

E

B

A

C

B

D

6 x 1.0 mm
12 N·m (1.2 kgf·m,
8.7 lbf·ft)

B

A

6 x 1.0 mm
12 N·m (1.2 kgf·m, 8.7 lbf·ft)

28. Clean and dry the oil pump mating surfaces.

29. Install the oil pump (A).

–1 Install a new crankshaft oil seal in the oil pump

(see page 8-10).

–2 Apply liquid gasket, P/N 08718-0001 or 08718-

0003, evenly to the block mating surface of the
oil pump and to the inner threads of the bolt
holes.

NOTE: Do not install the parts if 4 minutes or
more have elapsed since applying the liquid
gasket. Instead, reapply liquid gasket after
removing the old residue.

–3 Apply a light coat of multipurpose grease to

the lip of the oil seal and apply new engine oil
to the new O-ring (B).

–4 Install the dowel pins (C), then align the inner

rotor with the crankshaft and install the oil
pump.

–5 Clean the excess grease off the crankshaft and

check the seal for distortion.

30. Install the baffle plate (D), then install the oil screen

(E).

31. Install the oil pan (see page 7-28).

32. Install the timing belt drive pulley (A), then install

the crankshaft position (CKP) sensor (B).

33. Install the cylinder heads (see page 6-55).

34. Install the transmission:

• 1999-2001 models (see page 14-147).
• 2002-2004 models (see page 14-379).

35. Install the engine assembly (see page 5-12).

NOTE: Whenever any crankshaft or connecting rod
bearing is replaced, it is necessary after
reassembly to run the engine at idling speed until it
reaches normal operating temperature, then
continue to run it for about 15 minutes.

03/07/29 09:13:11 61S0X050_070_0027

*01

*02

*03

S0X4A00A18300043401KCAT00

7-28

Engine Block

Oil Pan Installation

A
10 x 1.25 mm
38 N·m (3.9 kgf·m,
28 lbf·ft)

6 x 1.0 mm
12 N·m (1.2 kgf·m,
8.7 lbf·ft)

B

1.

2. Clean and dry the oil pan mating surfaces.

3.

4. Install the oil pan on the cylinder block.

5. Tighten the bolts in two or three steps. In the final

step, tighten all bolts in sequence to 12 N·m
(1.2 kgf·m, 8.7 lbf·ft).

NOTE: After assembly, wait at least 30 minutes
before filling the engine with oil.

6. Tighten the two bolts (A) securing the transmission,

then install the torque converter cover (B).

7. Install the exhaust pipe A (see step 19 on page

8.

Apply liquid gasket
along the broken line.

03/07/29 09:13:11 61S0X050_070_0028

Remove any old liquid gasket from the oil pan
mating surfaces, bolts and bolt holes.

Apply liquid gasket, P/N 08718-0001 or 08718-003,
evenly to the oil pan mating surface of the cylinder
block and to the inner threads of the bolt holes.

NOTE: Do not install the parts if 4 minutes or more
have elapsed since applying liquid gasket. Instead,
reapply liquid gasket after removing the
old residue.

Refill the engine with oil (see page 8-5).

5-16).

*01

S0X4A00A18316617512KCAT00

*01

S0X4A00A18316617513KCAT00

Special Tools Required

Special Tools Required

7-29

7-29

Pulley End Crankshaft Seal
Installation - In Car

Transmission End Crankshaft Seal
Installation - In Car

070AD-RCA0100

07749-0010000

070AD-RCA0200

Oil seal driver 64 070AD-RCA0100

1. Clean and dry the crankshaft oil seal housing.

2. Apply a light coat of multipurpose grease to the

crankshaft and to the lip of the seal.

3. Using the seal driver, drive in the crankshaft oil seal

until the driver bottoms against the oil pump. When
the seal is in place, clean any excess grease off the
crankshaft, and check that the oil seal lip is not
distorted.

• Driver 07749-0010000
• Driver attachment 106 070AD-RCA0200

1. Clean and dry the crankshaft oil seal housing.

2. Apply a light coat of multipurpose grease to the

crankshaft and to the lip of the seal.

3. Using the special tools, drive the crankshaft oil seal

into the engine block end cover until the driver
attachment bottoms against the crankshaft. Align
the hole in the driver attachment with the pin on the
crankshaft.

4. Clean any excess grease off the crankshaft, and

check that the oil seal lip is not distorted.

03/07/29 09:13:12 61S0X050_070_0029
