2004 Model
Severe Driving Conditions
Part
Maintenance Items
3-28
Maintenance Schedule
Listed by Distance/Time for Severe Conditions (cont’d)
Use the Severe Conditions schedule if the vehicle is driven MAINLY in Canada or in any of the following conditions; if
only OCCASIONALLY driven in these conditions, use the Normal Conditions schedule.
•
•
•
•
•
Driving less than 5 miles (8 km) per trip or, in freezing temperatures, driving less than 10 miles (16 km) per trip.
Driving in extremely hot over 90°F (32°C) conditions.
Extensive idling, or long periods of stop-and-go driving, such as a taxi or a commercial delivery vehicle.
Trailer towing, driving with a roof rack, or driving in mountainous conditions.
Driving on muddy, dusty, or de-iced roads.
Do the items in parts A, B, C, D, E, F, and G as required for the mileage/time interval listed.
•
•
•
•
•
D
Inspect and adjust drive belts, every 30,000 miles (48,000 km) or 2 years.
Look for cracks and damage, then check belt deflection by pushing on the belt about 98 N (10 kgf, 22
lbf) midway between the pulleys.
P/S pump belt: 13.0
16.5 mm (1/2
Replace dust and pollen filter (see page 21-44), every 30,000 miles (48,000 km) or 2 years.
Replace the filter as often (at 15,000 miles/24,000 km intervals) if the vehicle is driven mostly in urban
areas that have high concentrations of soot in the air from industry and diesel-powered vehicles.
Replace the filter whenever airflow from the heating and cooling/climate control system is less than
normal.
Replace transmission fluid (see page 14-368), every 30,000 miles (48,000 km) or 2 years.
Capacity: 3.3
(3.5 US qt), use Honda ATF-Z1.
E
Replace timing belt (see page 6-20), and inspect water pump (see page 10-12), every 105,000 miles
(168,000 km) or 7 years.
•
•
F
Inspect valve clearance, otherwise adjust only if noisy (see page 6-15), every 105,000 miles (168,000 km).
Intake: 0.20
0.24 mm (0.008
0.009 in.), Exhaust: 0.28
0.32 mm (0.011
0.013 in.).
Replace spark plugs (see page 4-18), every 105,000 miles (168,000 km).
GAP: 1.0
1.1 mm (0.039
0.043 in.), use PZFR5F11 (NGK) or PKJ16CR-L11 (DENSO).
•
G
Replace engine coolant (see page 10-13), at 120,000 miles (192,000 km) or 10 years, then every 60,000
miles (96,000 km) or 5 years.
Use Honda All Season Antifreeze/coolant Type 2.
NOTE: According state and federal regulations, failure to do the maintenance items marked with an asterisk (
) will
not void the customer’s emissions warranties. However, Honda recommends that all maintenance services be done at
the recommended intervals to ensure long-term reliability.
03/07/29 09:06:20 61S0X050_030_0028
5/8 in.) (see page 17-13).
