Fig. 33: Positioning Wheel On Tire Machine And Tire Iron
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Inflate the tire to 300 kPa (3.1 kgf/cm

2

 , 44 psi) to seat the tire bead to the rim, then adjust the tire

pressure (see WHEEL ALIGNMENT ), and install the valve stem cap.

7. Check and adjust the wheel balance, then install the wheels on the vehicle. Torque the wheel nuts to

specifications.

8. Remove the jack stands, and lower the jack.

9. Connect the HDS and memorize the pressure sensor IDs using the TPMS sensor initializer tool (see

MEMORIZING THE TIRE PRESSURE SENSOR ID ).

NOTE:

Make sure the tire bead is seated on both sides of the rim uniformly.



2007 Honda Element EX

2007-2008 SUSPENSION TPMS (Tire Pressure Monitoring System) - Element



DTC TROUBLESHOOTING INDEX

DTC TROUBLESHOOTING CHART

DTC (MIL indication

(1)

)

Two Drive Cycle

Detection

Detection Item

MIL

P0010 (56)

--

Variable Valve Timing
Control (VTC) Oil Control
Solenoid Valve
Malfunction

ON

P0011 (56)

o

Variable Valve Timing
Control (VTC) System
Malfunction

ON

P0101 (50)

o

Mass Air Flow (MAF)
Sensor Circuit
Range/Performance
Problem

ON

P0102 (50)

--

Mass Air Flow (MAF)
Sensor Circuit Low
Voltage

ON

P0103 (50)

--

Mass Air Flow (MAF)
Sensor Circuit High
Voltage

ON

P0107 (3)

--

Manifold Absolute
Pressure (MAP) Sensor
Circuit Low Voltage

ON

P0108 (3)

--

Manifold Absolute
Pressure (MAP) Sensor
Circuit High Voltage

ON

P0111 (10)

o

Intake Air Temperature
(IAT) Sensor Circuit
Range/Performance
Problem

ON

P0112 (10)

--

Intake Air Temperature
(IAT) Sensor Circuit Low
Voltage

ON

P0113 (10)

--

Intake Air Temperature
(IAT) Sensor Circuit High
Voltage

ON

P0116 (86)

o

Engine Coolant
Temperature (ECT) Sensor
1 Circuit
Range/Performance
Problem

ON

P0117 (6)

--

Engine Coolant
Temperature (ECT) Sensor

ON



2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE Fuel and Emissions Systems - Element





2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE Fuel and Emissions Systems - Element



1 Circuit Low Voltage

P0118 (6)

--

Engine Coolant
Temperature (ECT) Sensor
1 Circuit High Voltage

ON

P0122 (7)

--

Throttle Position (TP)
Sensor A Circuit Low
Voltage

ON

P0123 (7)

--

Throttle Position (TP)
Sensor A Circuit High
Voltage

ON

P0125 (86)

o

Engine Coolant
Temperature (ECT) Sensor
1 Malfunction/Slow
Response

ON

P0128 (87)

o

Cooling System
Malfunction

ON

P0133 (61)

o

Air Fuel Ratio (A/F)
Sensor (Sensor 1)
Malfunction/Slow
Response

ON

P0134 (41)

o

Air Fuel Ratio (A/F)
Sensor (Sensor 1) Heater
System Malfunction

ON

P0135 (41)

--

Air Fuel Ratio (A/F)
Sensor (Sensor 1) Heater
Circuit Malfunction

ON

P0137 (63)

o

Secondary Heated Oxygen
Sensor (Secondary HO2S
(Sensor 2)) Circuit Low
Voltage

ON

P0138 (63)

o

Secondary Heated Oxygen
Sensor (Secondary HO2S
(Sensor 2)) Circuit High
Voltage

ON

P0139 (63)

o

Secondary Heated Oxygen
Sensor (Secondary HO2S
(Sensor 2)) Slow Response

ON

P0141 (65)

--

Secondary Heated Oxygen
Sensor (Secondary HO2S
(Sensor 2)) Heater Circuit
Malfunction

ON

P0171 (45)

o

Fuel System Too Lean

ON

P0172 (45)

o

Fuel System Too Rich

ON

P0222 (7)

--

Throttle Position (TP)
Sensor B Circuit Low

ON



2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE Fuel and Emissions Systems - Element



Voltage

P0223 (7)

--

Throttle Position (TP)
Sensor B Circuit High
Voltage

ON

P0300 (75) any
combination of the
following
P0301 (71)
P0302 (72)
P0303 (73)
P0304 (74)

o

Random Misfire Detected

ON

P0301 (71)

o

No. 1 Cylinder Misfire
Detected

ON

P0302 (72)

o

No. 2 Cylinder Misfire
Detected

ON

P0303 (73)

o

No. 3 Cylinder Misfire
Detected

ON

P0304 (74)

o

No. 4 Cylinder Misfire
Detected

ON

P0325 (23)

--

Knock Sensor Circuit
Malfunction

ON

P0335 (4)

--

Crankshaft Position (CKP)
Sensor No Signal

ON

P0339 (4)

--

Crankshaft Position (CKP)
Sensor Circuit Intermittent
Interruption

ON

P0340 (57)

--

Camshaft Position (CMP)
Sensor A No Signal

ON

P0341 (57)

--

Camshaft Position (CMP)
Sensor A and Crankshaft
Position (CKP) Sensor
Incorrect Phase Detected

ON

P0344 (57)

--

Camshaft Position (CMP)
Sensor A Intermittent
Interruption

ON

P0365 (8)

--

Camshaft Position (CMP)
Sensor B No Signal

ON

P0369 (8)

--

Camshaft Position (CMP)
Sensor B Circuit
Intermittent Interruption

ON

P0420 (67)

o

Catalyst System Efficiency
Below Threshold

ON

P0443 (92)

--

Evaporative Emission
(EVAP) Canister Purge
Valve Circuit Malfunction

ON
