Honda Element. Manual - part 733

cushion cover (C).

Fig. 55: Identifying Seat Cushion Cover And Hooks
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Release the hooks (A) from the seat cushion frame.

Fig. 56: Identifying Seat Cushion Frame Hooks
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Remove the hook (A) from the hook strap (B), and pull the hook strap out through the slit in the seat

cushion cover. If necessary, remove the bolt (C), then remove the hook strap.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 57: Identifying Hook Strap Bolt With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Remove the clip (D), and pull the strap (E) out.

7. Release the Velcro fastener (A), and remove the cover (B).

Fig. 58: Identifying Velcro Fastener And Cover
Courtesy of AMERICAN HONDA MOTOR CO., INC.

8. Release the hooks (A) securing the seat cushion cover (B) from the recline cover.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 59: Releasing Hooks Securing Seat Cushion Cover From Recline Cover
Courtesy of AMERICAN HONDA MOTOR CO., INC.

9. Pull back the seat cushion cover. Remove the screw (A), and pull the recline cover (B) down to release

the hook (C).

10. Remove the nut (D), then remove the recline strap (E) from the recline adjuster lever (F).

Fig. 60: Identifying Recline Strap Nut With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

11. Pull up on the center tray (A) to detach the clips, then remove the tray with the recline strap (B).



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 61: Identifying Center Tray Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

12. Pull back the edge of the seat cushion cover all the way around, and release the clips (A), then remove the

seat cushion cover (B).

Fig. 62: Identifying Seat Cushion Cover And Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

13. If necessary, remove the hinge covers (A).



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element
