Fig. 13: Identifying Velcro Fasteners And Seat-Back Cover
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Pull the seat-back cover, and release the hook (C).

7. Release the hook(s) (A) from the seat frame.

Fig. 14: Identifying Seat Frame Hooks
Courtesy of AMERICAN HONDA MOTOR CO., INC.

8. Pinch the tabs on the ends of the head restraint guides (A), and remove them from the seat-back.

'07 model



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 15: Identifying Head Restraint Guides (For '07 Model)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

'08 model

Fig. 16: Identifying Head Restraint Guides (For '08 Model)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

9. Using the appropriate trim tool, pry out on the front belt trim cap (A) to release the hooks (B), then

remove the screws securing the shoulder front seat trim (C).



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 17: Identifying Front Belt Trim, Hooks And Screws
Courtesy of AMERICAN HONDA MOTOR CO., INC.

10. Release the front hook (A) and rear hook (B) of the reinforcing cloth (C) from the seat-back frame (D).

Fig. 18: Removing Front Hook And Rear Hook Of Reinforcing Cloth From Seat-Back Frame
Courtesy of AMERICAN HONDA MOTOR CO., INC.

11. Passenger's seat: Remove the ODS unit cover (A), and disconnect the OPDS sensor connectors (B) from

the ODS unit (C), and pull them in through the hole (D) in the seat frame.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element



Fig. 19: Identifying ODS Unit Cover And OPDS Sensor Connectors
Courtesy of AMERICAN HONDA MOTOR CO., INC.

12. Passenger's seat: Release the wire ties (A) fastening the OPDS sensor harnesses (B) to the seat-back

frame spring (C).

Fig. 20: Identifying PDS Sensor Harnesses And Seat-Back Frame Spring
Courtesy of AMERICAN HONDA MOTOR CO., INC.

13. Turn over the seat-back cover (A), then remove the screws securing the shoulder front seat cover (B).



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Seats - Element
