Honda Element. Manual - part 718

Fig. 58: Identifying Tail Pipe With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

9. Refill the rear differential with the recommended fluid (see REAR DIFFERENTIAL FLUID

INSPECTION AND REPLACEMENT ).

10. Test-drive the vehicle.

REAR DIFFERENTIAL MOUNT REPLACEMENT

EXPLODED VIEW

M/T model



2007 Honda Element EX

2007-08 DRIVELINE/AXLES Rear Differential - Element



Fig. 59: Exploded View Of Rear Differential Mount With Torque Specifications (M/T Model)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

A/T model



2007 Honda Element EX

2007-08 DRIVELINE/AXLES Rear Differential - Element



Fig. 60: Exploded View Of Rear Differential Mount With Torque Specifications (A/T Model)
Courtesy of AMERICAN HONDA MOTOR CO., INC.



2007 Honda Element EX

2007-08 DRIVELINE/AXLES Rear Differential - Element



2007-08 SUSPENSION

Rear Suspension - Element

KNUCKLE/HUB/WHEEL BEARING REPLACEMENT

EXPLODED VIEW

Fig. 1: Exploded View Of Knuckle/Hub/Wheel Bearing With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Special Tools Required



2007 Honda Element EX

2007-08 SUSPENSION Rear Suspension - Element





2007 Honda Element EX

2007-08 SUSPENSION Rear Suspension - Element
