1. Remove the ball bearing (A) from the clutch housing (B) using the 20-40 mm adjustable bearing puller

(C) and a commercially available 3/8 "-16 UNF slide hammer (D).

Fig. 126: Removing Ball Bearing Of Clutch Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Remove the 28 x 43 x 7 mm oil seal (A) from the transmission side. Be careful when removing the seal so

the clutch housing is not damaged.

Fig. 127: Removing Oil Seal
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Drive in the new 28 x 43 x 7 mm oil seal from the transmission side using the 42 x 47 mm attachment (A)

and driver (B).



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element



Fig. 128: Installing Oil Seal
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Drive in the new ball bearing (A) from the transmission side using the oil seal driver (B).

Fig. 129: Installing Ball Bearing Of Transmission Side
Courtesy of AMERICAN HONDA MOTOR CO., INC.

COUNTERSHAFT BEARING REPLACEMENT

Special Tools Required



Oil seal driver 07JAD-PL90100



Adjustable bearing puller, 20-40 mm 07736-A01000B



Slide hammer, 3/8 "-16 UNF commercially available

1. Remove the bearing set plate (A) from the clutch housing (B).



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element



Fig. 130: Identifying Bearing Set Plate And Clutch Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Remove the needle bearing (A) using the 20-40 mm adjustable bearing puller (B) and a commercially

available 3/8 "-16 UNF slide hammer (C), then remove the oil guide plate C (D).

Fig. 131: Removing Needle Bearing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Position the oil guide plate C (A) and new needle bearing (B) in the bore of the clutch housing (C).

Fig. 132: Positioning Oil Guide Plate, Needle Bearing And Clutch Housing



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element



Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Install the needle bearing using the oil seal driver (D).

5. Install the bearing set plate (A) with bolts (B).

Fig. 133: Identifying Bearing Set Plate With Bolts With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

MAINSHAFT THRUST CLEARANCE ADJUSTMENT

Special Tools Required



Mainshaft holder 07GAJ-PG20110



Mainshaft base 07GAJ-PG20130

1. Remove the 72 mm shim (A) and oil guide plate M from the transmission housing (B).

Fig. 134: Identifying Shim, Oil Guide Plate M And Transmission Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Thoroughly clean the 28 mm spring washer (A) and 28 mm washer (B) before installing them on the

clutch housing side bail bearing (C).



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element
