3. Install the rear transmission mount bracket (A) and the rear transmission mount (B).

4WD

Fig. 25: Identifying Rear Transmission Mount Bracket And Rear Transmission Mount (4WD)
With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2WD

Fig. 26: Identifying Rear Transmission Mount Bracket And Rear Transmission Mount (2WD)
With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Place the transmission on the transmission jack, and raise it to the engine level.

5. Install the four lower transmission mounting bolts.

2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element

Fig. 27: Identifying Lower Transmission Mounting Bolts With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Install the front engine mount (A).

Fig. 28: Identifying Front Engine Mount With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Install the clutch cover (A).

2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element

Fig. 29: Identifying Clutch Cover With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

8. Lift and support the front subframe (A) with the front subframe adapter (B) and a jack(C).

Fig. 30: Identifying Front Subframe, Front Subframe Adapter And Jack
Courtesy of AMERICAN HONDA MOTOR CO., INC.

9. Install the front subframe (A) in its original position by aligning it with the marks (B) you made in the

removal procedure.

2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element

Fig. 31: Identifying Front Subframe With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

10. Install the three bolts for the rear transmission mount.

Fig. 32: Identifying Bolts For Rear Transmission Mount With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

11. Loosely install the front engine mount bracket bolt (A).

2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element
