Fig. 26: Identifying Clips Of Body
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Hold the trim (A) up, and fit the clips (B, C) into the holes in the body, then push on the trim until the

clips snap into place.

Fig. 27: Identifying Trim And Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

8. Install the bolts, and install the lids.

REAR TRIM

1. Remove the center trim rear lid from the roof side center trim, and remove the bolt.

2. Open the hatch, and remove the bolt from the rear portion of the roof side rear trim.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Exterior Trim - Element



Fig. 28: Identifying Roof Side Rear Trim Rear Portion Bolt With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Slide the trim (A) rearward to release it from the clips, then remove the trim. The clips will stay in the

body. Take care not to scratch the body.

Fig. 29: Identifying Trim Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Using a clip remover, remove the clips from the body.

5. Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones, and

install them on the trim.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Exterior Trim - Element



Fig. 30: Identifying Clips Of Body
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Insert the front edge of the trim (A) between the roof side center trim (B) and body, and fit the clips into

the holes in the body, then push on the trim until the clips snap into place.

Fig. 31: Identifying Front Edge Of Trim Between Roof Side Center Trim Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

7. Install the bolts, and install the center trim rear lid.

SIDE SILL PANEL REPLACEMENT

1. On the front of the rear wheel arch, remove the screw securing the rear side sill panel (A).

NOTE:

Put on gloves to protect your hands.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Exterior Trim - Element



Fig. 32: Identifying Rear Side Sill Panel Screw
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Pull the front edge of the rear side sill panel (A) out, and hold it. Slide the panel forward to release it from

the clips, then remove the panel. The clips will stay in the body.

Fig. 33: Identifying Rear Side Sill Panel
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Remove the clips from the body by turning them 45°.

4. On the back of the front wheel arch, remove the screws securing the front side sill panel (A).
