Fig. 2: Identifying Hooks, Front Bumper Upper Face And Front Grille
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. If necessary, separate the front emblem (A) from the emblem base (B) by removing the push nuts (C), and

release the hook (D), then remove the front emblem base from the front grille (E).

Fig. 3: Identifying Emblem Base, Nuts, Hook And Front Emblem Base
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Install the grille in the reverse order of removal, and note these items:



Push the hooks into place securely.



Replace the push nuts with new ones.

LX, EX MODELS



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Exterior Trim - Element



1. Remove the front bumper (see FRONT BUMPER REMOVAL/INSTALLATION ).

2. Remove the screws (A).

Fig. 4: Identifying Clips, Hooks And Front Grille
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Detach the clips (B), and release the hooks (C), then remove the front grille (D) from the front bumper by

pulling it out.

4. Install the grille in the reverse order of removal, and note these items:



Make sure the rear hooks of the grille engage the bumper securely.



Push the clips and hooks into place securely.



Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones.

FRONT GRILLE MOLDINGS REPLACEMENT

LX, EX models

1. Remove the front grille.

2. Separate the front emblem (A) from the front grille molding (B) by removing the push nuts (C).

NOTE:



Take care not to scratch the front bumper.



Put on the gloves to protect your hands.

NOTE:

Take care not to scratch the front bumper.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Exterior Trim - Element



Fig. 5: Identifying Front Emblem, Front Grille Molding And Push Nuts
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Remove the screws, and remove the front grille molding from the front grille base (D).

4. Install the molding in the reverse order of removal. Replace the push nuts with new ones.

COWL COVER REPLACEMENT

1. Remove the windshield wiper arms (see WIPER ARM/NOZZLE ADJUSTMENT ).

2. Remove the passenger's cowl cover (A) and the driver's cowl cover (B). Take care not to scratch the

body.

-1 Using a clip remover, detach the clips (C), then remove the hood rear seal (D).

-2 Using a clip remover, remove the clips (E) from the cowl covers.

-3 Release the windshield washer tube (F).

-4 Detach the clips (G, H) and release the hooks (I, J) by carefully pulling the passenger's cowl
cover upward.

-5 Pull the cover forward to release the hooks (K), and pull the hinge cover (L) out from the front
fender (M), then remove the passenger's cowl cover.

-6 Detach the clips (G, H, N), and release the hook (O) by carefully pulling the driver's cowl cover
upward.

-7 Pull the cover forward to release the hooks (P), and pull the hinge cover (Q) out from the front
fender (R), then remove the driver's cowl cover.



2007 Honda Element EX

2007-08 ACCESSORIES AND EQUIPMENT Exterior Trim - Element



Fig. 6: Identifying Cowl Cover Clips
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Install the cowl covers in the reverse order of removal, and note these items:



Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones.



Push the clips and hooks into place securely.

A-PILLAR CORNER TRIM REPLACEMENT

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

1. Open the door.

2. Apply protective tape around the body to prevent damage. Carefully insert the appropriate tool from the

NOTE:

Use the appropriate tool from the KTC trim tool set to avoid damage when
prying components.
