TPMS SUBHARNESS

CONNECTOR TO HARNESS INDEX

(1)

Except SC model

(2)

SC model

(3)

Except '07 USA models

Connector or Terminal

Ref Cavities

Location

Connects to

Notes

TPMS control unit connector A

6

14

Under middle of dash



TPMS control unit connector B

5

20

Under middle of dash



C855

7

6

Under middle of dash Dashboard wire harness A



2007 Honda Element EX

2007-2008 ELECTRICAL Connectors and Harnesses - Element



Fig. 12: Identifying Dashboard Wire Harness A (Right Branch)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

ECM/PCM WIRE HARNESS

CONNECTOR TO HARNESS INDEX

Connector or Terminal

Ref Cavities Location

Connects to

Notes

A/T gear position indicator
panel light/park pin switch

11

4

Under
middle of
dash



A/T

A/T reverse relay

17

4

Behind
glove box



A/T

Air fuel ratio (A/F) sensor
relay

16

4

Behind
glove box





Data link connector (DLC)

28

16

Under left
side of dash





ECM/PCM connector D

14

17

Behind
glove box





ECM/PCM connector E

13

31

Behind
glove box





Throttle actuator control
module relay

19

4

Behind
glove box





Ignition coil relay

18

4

Behind
glove box





Memory erase signal (MES)
connector (see UNDER-DASH
FUSE/RELAY BOX )

1

2

Under left
side of dash





PGM-FI main relay 1 (FI
MAIN)

20

4

Behind
glove box





PGM-FI main relay 2 (FUEL
PUMP)

21

5

Behind
glove box





Rear accessory power socket
relay

15

4

Behind
glove box





Shift lock solenoid/D3 switch

24

4

Under
middle of
dash



A/T

Under-dash fuse/relay box
connector D (see UNDER-
DASH FUSE/RELAY BOX )

4

12

Under left
side of dash





Under-dash fuse/relay box
connector E (see UNDER-
DASH FUSE/RELAY BOX )

5

13

Under left
side of dash





Under-dash fuse/relay box
connector G (see UNDER-
DASH FUSE/RELAY BOX )

7

10

Under left
side of dash







2007 Honda Element EX

2007-2008 ELECTRICAL Connectors and Harnesses - Element



Under-dash fuse/relay box
connector H (see UNDER-
DASH FUSE/RELAY BOX )

2

3

Under left
side of dash





Under-dash fuse/relay box
connector P (see UNDER-
DASH FUSE/RELAY BOX )

6

18

Under left
side of dash





Under-dash fuse/relay box
connector Q (see UNDER-
DASH FUSE/RELAY BOX )

3

8

Under left
side of dash





Under-dash fuse/relay box
connector R (see UNDER-
DASH FUSE/RELAY BOX )

8

6

Under left
side of dash





C101

12

20

Behind
glove box

Engine wire harness (see ENGINE
WIRE HARNESS )



C451

27

20

Under
middle of
dash

Engine compartment wire harness (see
ENGINE COMPARTMENT WIRE
HARNESS (DASHBOARD) )



C452

26

3

Under
middle of
dash

Engine compartment wire harness (see
ENGINE COMPARTMENT WIRE
HARNESS (DASHBOARD) )



C453

9

14

Under
middle of
dash

Dashboard wire harness A (see
DASHBOARD WIRE HARNESS A
(LEFT BRANCH) )



C454

25

12

Under
middle of
dash

Dashboard wire harness A (see
DASHBOARD WIRE HARNESS A
(RIGHT BRANCH) )



C455

22

17

Under
middle of
dash

Floor wire harness (see FLOOR WIRE
HARNESS (RIGHT BRANCH) )



C456

23

10

Under
middle of
dash

Floor wire harness (see FLOOR WIRE
HARNESS (RIGHT BRANCH) )



C457 (Junction connector)

10

20

Under
middle of
dash





G451

29



Under
middle of
dash

Body ground, via ECM/PCM wire
harness





2007 Honda Element EX

2007-2008 ELECTRICAL Connectors and Harnesses - Element



Fig. 13: Identifying ECM/PCM Wire Harness
Courtesy of AMERICAN HONDA MOTOR CO., INC.

FLOOR WIRE HARNESS (LEFT BRANCH)

CONNECTOR TO HARNESS INDEX

Connector or Terminal Ref Cavities

Location

Connects to

Notes

Driver's seat belt buckle

3

3

Under driver's
