Honda Element. Manual - part 276

Fig. 441: Tapping Oil Seal
Courtesy of AMERICAN HONDA MOTOR CO., INC.

COUNTERSHAFT BEARING REPLACEMENT

Special Tools Required



Adjustable bearing puller, 25-40 mm 07736-A01000B or 07736-A01000A



Driver 07749-0010000



Attachment, 62 x 68 mm 07746-0010500

1. Remove the countershaft bearing with the adjustable bearing puller and a commercially available 3/8 "-16

slide hammer (A).

Fig. 442: Identifying Countershaft Bearing With Adjustable Bearing Puller
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Remove the ATF guide plate (A), and check it for wear and damage. If the guide plate is worn or

damaged, replace it.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 443: Identifying ATF Guide Plate And Countershaft Bearing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Install the ATF guide plate in the housing, and install the new countershaft bearing (B).

4. Install the new countershaft bearing securely in the housing with the driver and the 62 x 68 mm

attachment.

Fig. 444: Tapping Countershaft Bearing In Housing
Courtesy of AMERICAN HONDA MOTOR CO., INC.

5. Make sure that the bearing outer race notch-cut (A) is installed at a height of 0-0.05 mm (0-0.002 in.) (B)

above the housing surface (C). Do not install the bearing higher than 0.05 mm (0.002 in.) above the
housing surface.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 445: Identifying Bearing Outer Race Notch-Cut Installation Position
Courtesy of AMERICAN HONDA MOTOR CO., INC.

SECONDARY SHAFT BEARING REPLACEMENT

Special Tools Required



Driver 07749-0010000



Attachment, 62 x 68 mm 07746-0010500

1. Remove the bolt, then remove the lock washer (A) and bearing set plate (B).

Fig. 446: Identifying Lock Washer And Bearing Set Plate With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Remove the secondary shaft bearing (A) by heating the housing to about 212°F (100°C) with a heat gun

(B). Do not heat the housing more than 212°F (100°C).



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 447: Identifying Secondary Shaft Bearing Heating Gun
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Install the new O-rings (A) on the ATF guide collar (B), then install the ATF guide collar in the housing.

Fig. 448: Identifying O-Rings On ATF Guide Collar
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Install the new secondary shaft bearing (C) in the direction shown.

5. Install the new secondary shaft bearing with the driver and 62 x 68 mm attachment securely in the

housing.

NOTE:

Let the housing cool to normal temperature before installing the bearing.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element
